Black And Blue Color Options Carbide End Mill Cutter AlTiN And NACo Coating On Carb
Black and Blue Color Options for AlTiN and nACo Coating on Carbide End Mill Cutter for a Professional Look
Specially suitable for: quenched steel SKD61 S136, Processing of pre hardened steel NAK80, ordinary mold steel, alloy steel, cast iron and other materials.
Peripheral milling (slab milling) - the surface being machined is parallel to the (often helical) cutting teeth in the periphery of the tool. End milling - fluted cutting edges are arranged on the circumference and end of a rotating shaft that is vertical to the workpiece.
Main features:
1. Using high-quality fine-grained hard alloy matrix, the tool wear resistance and cutting edge strength are superior combined.
2. Apply high-performance composite coatings imported from Switzerland to give the cutting tools higher hardness and wear resistance.
3. Strict and scientific groove design ensures high rigidity and high-precision quality control, achieving good universal performance of processed materials.
| Outer diameter D | Blade length H | Handle diameter d | Total length L |
| 1.0 | 3 | 4 | 50 |
| 1.5 | 5 | 4 | 50 |
| 2.0 | 6 | 4 | 50 |
| 2.5 | 8 | 4 | 50 |
| 3.0 | 9 | 4 | 50 |
| 4.0 | 10 | 4 | 50 |
| 5.0 | 13 | 5 | 50 |
| 5.0 | 15 | 6 | 50 |
| 6.0 | 15 | 6 | 50 |
| 8.0 | 20 | 8 | 60 |
| 10.0 | 25 | 10 | 75 |
| 12.0 | 30 | 12 | 75 |
| 14.0 | 45 | 14 | 100 |
| 16.0 | 45 | 16 | 100 |
| 18.0 | 45 | 18 | 100 |
| 20.0 | 45 | 20 | 100 |
| 4.0 | 14 | 4 | 75 |
| 5.0 | 20 | 5 | 75 |
| 5.0 | 20 | 6 | 75 |
| 6.0 | 24 | 6 | 75 |
| 8.0 | 30 | 8 | 75 |
| 4.0 | 20 | 4 | 100 |
| 5.0 | 25 | 5 | 100 |
| 5.0 | 25 | 6 | 100 |
| 6.0 | 30 | 6 | 100 |
| 8.0 | 35 | 8 | 100 |
| 10.0 | 40 | 10 | 100 |
| 12.0 | 45 | 12 | 100 |
| 6.0 | 45 | 6 | 150 |
| 8.0 | 50 | 8 | 150 |
| 10.0 | 60 | 10 | 150 |
| 12.0 | 60 | 12 | 150 |
| 14.0 | 70 | 14 | 150 |
| 16.0 | 75 | 16 | 150 |
| 18.0 | 75 | 18 | 150 |
