6mm Carbide End Mill Cutter For Stainless Steel With Tungsten Carbide Material And High-Performance
6mm Carbide End Mill Cutter for Stainless Steel with Tungsten Carbide Material and High-Performance
Specially suitable for high-speed processing of quenched steel S136/SKD61/SKD11/DC53 and other high hardness materials after heat treatment
A weakness of carbide drills is their low toughness. Low toughness means that the tool is more likely to break under bending or vibration, requiring proper management of chips which can cause these issues.
Main features:
1. Adopting imported high-quality ultra-fine particle hard alloy matrix, the tool wear resistance and cutting edge strength are superior combined.
2. Applying high-performance composite coatings imported from Switzerland to give the cutting tools better high-temperature hardness and stability.
3. Strict and scientific groove design ensures high rigidity and high-precision quality control, achieving excellent performance in processing high hardness materials.
| Outer diameter D | Blade length H | Handle diameter d | Total length L |
| 1.0 | 3 | 4 | 50 |
| 1.5 | 4 | 4 | 50 |
| 2.0 | 6 | 4 | 50 |
| 2.5 | 8 | 4 | 50 |
| 3.0 | 8 | 4 | 50 |
| 4.0 | 10 | 4 | 50 |
| 5.0 | 13 | 5 | 50 |
| 5.0 | 15 | 6 | 50 |
| 6.0 | 15 | 6 | 50 |
| 8.0 | 20 | 8 | 60 |
| 4.0 | 16 | 4 | 75 |
| 5.0 | 20 | 5 | 75 |
| 5.0 | 20 | 6 | 75 |
| 6.0 | 24 | 6 | 75 |
| 8.0 | 25 | 8 | 75 |
| 10.0 | 25 | 10 | 75 |
| 12.0 | 30 | 12 | 75 |
| 4.0 | 20 | 4 | 100 |
| 5.0 | 25 | 5 | 100 |
| 5.0 | 25 | 6 | 100 |
| 6.0 | 25 | 6 | 100 |
| 8.0 | 30 | 8 | 100 |
| 10.0 | 30 | 10 | 100 |
| 12.0 | 35 | 12 | 100 |
| 14.0 | 40 | 14 | 100 |
| 16.0 | 45 | 16 | 100 |
| 18.0 | 45 | 18 | 100 |
| 20.0 | 45 | 20 | 100 |
