Multi Flute Carbide End Mill Cutter For Precise Milling Of Hardened Steel And Other Materials
Multi Flute Carbide End Mill Cutter for and Precise Milling of Hardened Steel and Other Materials
Suitable for processing: ordinary carbon steel, alloy steel, pre hardened steel, stainless steel, copper, etc.
The main difference between these two milling processes is in the cutting device. Face mills have a fine circular design with cutting teeth for horizontal cutting. While end mills, which are usually screw-like, have cutting teeth on the face and sides, which permits end cutting and peripheral cutting.
Main features:
1. Using high-quality tungsten steel base material from China and TiAlN nano coating imported from Switzerland.
2. Adopting a special angle design and strict quality control.
| Outer diameter D | Blade length H | Handle diameter d | Total length L |
| 4.0 | 14 | 4 | 50 |
| 4.0 | 14 | 4 | 75 |
| 5.0 | 13 | 5 | 50 |
| 5.0 | 20 | 6 | 75 |
| 6.0 | 15 | 6 | 50 |
| 6.0 | 24 | 6 | 75 |
| 8.0 | 20 | 8 | 60 |
| 8.0 | 30 | 8 | 75 |
| 10.0 | 25 | 10 | 75 |
| 12.0 | 30 | 12 | 75 |
| 4.0 | 20 | 4 | 100 |
| 5.0 | 25 | 5 | 100 |
| 6.0 | 30 | 6 | 100 |
| 8.0 | 35 | 8 | 100 |
| 10.0 | 40 | 10 | 100 |
| 12.0 | 45 | 12 | 100 |
| 14.0 | 45 | 14 | 100 |
| 16.0 | 45 | 16 | 100 |
| 18.0 | 45 | 18 | 100 |
| 20.0 | 45 | 20 | 100 |
| 6.0 | 45 | 6 | 150 |
| 8.0 | 50 | 8 | 150 |
| 10.0 | 60 | 10 | 150 |
| 12.0 | 60 | 12 | 150 |
| 14.0 | 70 | 14 | 150 |
| 16.0 | 75 | 16 | 150 |
| 18.0 | 75 | 18 | 150 |
| 20.0 | 75 | 20 | 150 |
