Tungsten Carbide End Mill Cutter With Special Angle For High Precision Heat Treatment Die Steel
Tungsten Carbide End Mill Cutter with Special Angle for High Precision Heat Treatment Die Steel
Especially suitable for: P20 ,H13 ,S136,718H,NAK80,SKD61,S136, High speed processing of materials such as cast iron and stainless steel.
The main difference between these two milling processes is in the cutting device. Face mills have a fine circular design with cutting teeth for horizontal cutting. While end mills, which are usually screw-like, have cutting teeth on the face and sides, which permits end cutting and peripheral cutting.
Main features:
1. Using high-quality ultra-fine particle hard alloy matrix, the tool wear resistance and cutting edge strength are superior combined.
2. Apply high-performance nanocomposite coatings imported from Switzerland to give the cutting tools higher hardness and wear resistance.
3. Adopting a large helix angle design and strict quality control, it is suitable for high-speed machining stability and versatility.
| Outer diameter D | Blade length H | Handle diameter d | Total length L |
| 1.0 | 3 | 4 | 50 |
| 1.5 | 5 | 4 | 50 |
| 2.0 | 6 | 4 | 50 |
| 2.5 | 8 | 4 | 50 |
| 3.0 | 9 | 4 | 50 |
| 4.0 | 10 | 4 | 50 |
| 5.0 | 13 | 5 | 50 |
| 5.0 | 15 | 6 | 50 |
| 6.0 | 15 | 6 | 50 |
| 8.0 | 20 | 8 | 60 |
| 10.0 | 25 | 10 | 75 |
| 12.0 | 30 | 12 | 75 |
| 14.0 | 45 | 14 | 100 |
| 16.0 | 45 | 16 | 100 |
| 18.0 | 45 | 18 | 100 |
| 20.0 | 45 | 20 | 100 |
| 4.0 | 14 | 4 | 75 |
| 5.0 | 20 | 5 | 75 |
| 5.0 | 20 | 6 | 75 |
| 6.0 | 24 | 6 | 75 |
| 8.0 | 30 | 8 | 75 |
| 4.0 | 20 | 4 | 100 |
| 5.0 | 25 | 5 | 100 |
| 5.0 | 25 | 6 | 100 |
| 6.0 | 30 | 6 | 100 |
| 8.0 | 35 | 8 | 100 |
| 10.0 | 40 | 10 | 100 |
| 12.0 | 45 | 12 | 100 |
| 6.0 | 45 | 6 | 150 |
| 8.0 | 50 | 8 | 150 |
| 10.0 | 60 | 10 | 150 |
| 12.0 | 60 | 12 | 150 |
| 14.0 | 70 | 14 | 150 |
| 16.0 | 75 | 16 | 150 |
| 18.0 | 75 | 18 | 150 |
| 20.0 | 75 | 20 | 150 |
