ISO7810 Smart Card Reader Module , Magnetic Card Reader Module 3 tracks
Price:
Negotiable
MOQ:
5
Delivery Time:
<15 days
Brand:
Ming tech
Product Description
Magnetic track card reader module (Manual)
Features:
Ø magnetic stripe card reader;
Ø Input wrong alarm& status indicators;
Ø ISO7810/ISO7811 standard;
Ø 170mm Triple-track magnetic stripe card reader.
Ø All 3 tracks can set to 75/300 BPI;
Ø Head reliable for 800,000 time card swipes.
Specifications:
| Project | Parameters Of Specifications |
| Scanning function | |
| Direction | Dual face swipes, in&out same direction. |
| Codec. | F2F(FM) |
| Power source |
USB cable |
| Supply current function | USB |
| Serial communication | USB |
| Stack space | 1.5mm |
| Scanning speed | 15~120 cm/s |
| Card thickness | 0.2~0.84mm card |
| Card position | matching the head |
| Size | 90mm*27mm*28mm |
| Weight | 75 g |
| Other | |
| Data input function | Manual or Auto |
| Sensor | Card swipe detect. |
| Shutdown protection | Yes(extra cable reserve) |
| Connection | USB2.0 full speed |
| Switch | Power source |
| Indicators | 2 LED lights,power source&status indicators. (IF pass will flash once; failure will flash thrice.) |
| Cable length |
1.5 meters |
| Drive | Non |
| Environmental. |
Running Temp:0℃ - 50℃； Storage Temp:-30℃ - 70℃； Humidity:95% |
| All in one | Different standard for different countries; |
| Advanced | Full self-intellectural property; |
| Almighty | Apply to kinds of data collection device demands; |
| Excellent | Help you got a small RIFD reader easily; |
| Humanist | Standard interface for easy development; |
| Wide use | Best choice for small fixed reader; |
