3*18M Industrial Truck Scales Q235 Steel 50 Ton Electronic Digital Lorry Weighing
3*18M Q235 Steel 50 Ton Electronic Digital Lorry Weighing Scales
Standard configuration of digital Lorry Weighing Scales:
weighing platform, high accuracy weighing load cell and weighing indicator. Printer, scoreboard and computer management system are optional so as to complete the requirements of data management and transmission on the higher level.
Main features of digital Lorry Weighing Scales::
1. Use U-shape beam structure, scientific and reasonable, strong and durable;
2. Undersurface uses high quality antirust paint so as to increase its service life;
3. Modular, sealed cavity, anticorrosion, convenient installation.
Main features of weighing indicator:
1. use imported A/D conversion chip, which has rich practical experience in the market;
2. high resolution, can reach 1/500000;
3. self fault diagnosis function and tare two-way recovery function;
4. battery indication and low battery protection;
5. can use single-layer, duplex and three-ply weight list, can be equipped with weighing software and connected to the computer.
Main technical parameters of weighing load cell:
| Weighing load cell | Cantilever beam type | Bridge type | Colum type |
| Rated load(t) | 0.5,1,2,5,10,20 | 10,15,20,25,30,40,50 | 20,30,50 |
| Rated output(m/v) | 2±0.01 | 2±0.01 | 1.0±0.04 |
| Input resistance(Ω) | 400±5 | 750±5 | 450±5 |
| Output resistance(Ω) | 351±1 | 700±1 | 350±5 |
| Non-repeatability(%FS) | ±0.02 | ±0.02 | ±0.02 |
| Recommended excitation(V) | 10DC | 10DC | 10DC |
| Width(m) | Weighing platform length(m) | |||||||||
| 7 | 9 | 10 | 12 | 14 | 15 | 16 | 18 | 20 | 21 | |
| 3 | * | * | * | * | * | |||||
| 3.2 | * | * | * | |||||||
| 3.4 | * | * | * | * | ||||||
| Our company accepts special specification order. * represents optimal specifications. | ||||||||||
| Model: SCS-60T | Maximum weighing(T): 60 | Division value(kg): 10, 20 | ||||||||
