SCS 3x10m 30 Ton Industrial Truck Scales 150%FS Overload Electronic Vehicle Weighing Systems

Name: SCS 3x10m 30 Ton Industrial Truck Scales 150%FS Overload Electronic Vehicle Weighing Systems
Brand: Changsha Purple Horn E-Commerce Co., Ltd.

Price Negotiable

Price: Negi

MOQ: 1 set

Delivery Time: 10~25 days

Brand: Purple Horn

Product Description

5/10KG Accuracy 50 Ton Electronic Digital Dynamic Weighbridge

Truck scale introduction:

Truck scale (weighbridge) platform, high accuracy weighing load cells, weight indicator, junction box and shield cable are necessary parts of a basic truck scale (weighbridge). Printer, scoreboard and computer management system are optional so as to complete the requirements of data management and transmission on the higher level.

Plate Material	Q235 carbon steel, 8/10/12mm steel plate is optional
Indicator/Display	Analog A9, A9P optional(OIML&CE approved), Digital Yaohua DS10 or DS8 and Keli D2008H
Load Cells	Keli or Zemic bridge type digital load cells
Display Designators	On/Off, Zero, Tare, kg/lb.
Transmission Distance	RS232C≤30m
Power Supply	Rechargeable Battery, AC 220V;50Hz (-2%~+2%), DC 12V/7AH
Junction box	Anti-surge junction box, 4, 6,8,10,12-wire are optional, adapt to all weighing systems
Signal cable	20m single shielded 4-core cable, can't cut when use otherwise will effect accurate
Color	Standard color

Recommended dimension for Purple Horn truck scale platform
Capacity(Tons)	30	40	50	60	80	100	120	150
Division Value	5KG/10KG/20KG/50KG
Platform size:L*W(m)	Recommended size								Packing(container)
3*7	√	√							1x20'GP
3*9	√	√	√	√	√				1x20'GP
3*12	√	√	√	√	√	√			1x20'GP
3*14	√	√	√	√	√	√			1x20'GP
3*16		√	√	√	√	√			1x20'GP
3*18			√	√	√	√	√		1x20'GP
3*20					√	√	√	√	1x40'GP
3*22						√	√	√	1x40'GP
3*24							√	√	1x40'GP
Remark	Other capacity, size and apprearance can be customized according your requirements.
