10MM White Endless Nomex Felt Belt For Heat Transfer Printing Machine

DESCRIPTION

Blanket imported DuPont aramid 1313, the middle fabric for high-performance industrial silk fabric. It can work under 250°C. After the use, the shrinkage of the door width is 3%, the elongation is 3%, the weight is 3300g/m2, the thickness is 8mm, and it can also be customized according to customer's demand. The thickness is 3600g. /m2 is a special blanket for the transfer printing of various fabrics, curtain fabrics, and decorative fabrics. Specifications can be customized according to customer needs.

ADVANTAGE

1. 100% Nomex raw material

2. The max temperature resistant 280℃

3. Endless type - no joint(Don't worry about the fracture)

4. Misaligned----Our base cloth is used endless industrial silk. The testing report showed the misaligned rate is about ±3mm. enclosed our base cloth for your consideration

5. Shrinkage----The base cloth can control the shrinkage rate by 2.5%--3%.

SPECIFICATION

ADVANTAGE

1. 100% Nomex raw material

2. The max temperature resistant 280℃

3. Endless type - no joint(Don't worry about the fracture)

4. Misaligned----Our base cloth is used endless industrial silk. The testing report showed the misaligned rate is about ±3mm. enclosed our base cloth for your consideration

5. Shrinkage----The base cloth can control the shrinkage rate by 2.5%--3%.

APPLICATION

1. Selection Of Brand Raw Material, Common Specifications Have Temperature 160-180℃ And 220-280℃.

2. The Felt Belt Contains Heat Shrinkable Fiber Material Inside, The Felt Will Automatically Shrink After Heating, Wrapped Tightly.

3. The Belt Surface Formation, Uniform Density, Good Resistance, Long Work Life.

DIRECTION OF OUR FELT BELT

1. The blanket must be install as the direction of the arrow, fixing both sides of the perimeter

to see if the perimeter is the same.

2. Adjust the machine pressure within 2kg. heat up to 150 ℃, idle for 2 hours; heat up to

170℃, idle for 2 hours; heat up to 190℃, idle 3 hours( important); heat up to 200℃,

idle for 2 hours.

3. Then the belt will suitable for your machine, you can adjust the machine pressure in 3--5kg

according to your needed and start printing.

Package&Delivery

Package: plastic bag+carton

Delivery: Express company & by air & by sea or as your demands

FAQ

1. How long it can be used?

It depends on your scale of production and your use custom.

2. The Sample is free?

Yes, if you need the samples, we will send it to you freely. but I hope you pay the freight. thank you.

3. What is the lead time?

About 7 working days.

4. What is packing?

By air & by sea or as your demands

Design Your Belt

Operation Temperature: 180℃,280℃                                      Your operation temperature:_____

Material:aramid/Nomex                                                            Your request material:__________
Thickness:6mm,7mm,8mm,10mm                                           Your request width:____________
Width and length can be customed                                           Your request:_________________

Contact us to get the quotation details.
