4-1/2" Diameter Johnson Wire Wrap Screens Mesh With 50um Slot
Stainless Steel 304 4-1/2" Diameter Johnson Wire Wrapped Screen Mesh
Johnson wire wrapped screen mesh, Also be named profile wire wrap screen,Johnson screen, water well screen, water wire screen,wound screen.
| Johnson Wire Wrapped Screen Mesh Sizes: | ||
| Name | Johnson wire wrapped screen mesh | |
|
Specification (Profile wire): VEE-shaped Wire: (Width*height) |
Width(mm): 1.0 1.2 1.5 2.0 2.2 3.0 3.2 Height(mm): 2.0 2.5 3.5 4.6 5.0 6.0 |
|
|
Specification (support rods): VEE-shaped Wire: (Width*height) |
Width(mm): 2.0 3.0 Height(mm): 3.0 4.6 5.0 6.0 7.0 Round: From 2.50mm to 6.0mm |
|
| Note: other wires and rods available upon request. | ||
| Slot size (um) | 50,100,150,200,250,300……also achieved upon request. | |
| Material: | AISI 304, 304L, 316L ,321 etc. | |
| Length | Upto 4 meters | |
| Application | Filtration | |
| Features | Non-clogging | |
| Use | In wastewater treatment | |
| Diameter | 29-1300mm | |
| Screen end | Plain beveled ends, male/female threaded, flange, close up.Open ends | |
| Other sizes available on request. | ||
|
Advantage
|
Reduce energy consumption and increase water flow. Reduce erosion of entry surfaces and increase well life. Allow a uniform and efficient well development. Reduce significantly potential pump damage and subsequent maintenance costs. |
|
Johnson Wire Wrapped Screen Mesh Advantages:
Johnson Wire Wrapped Screen Mesh Applications:
Outside to intside flow
