Premium Indution Pipe Bending Machine 200 - 1000KW Heating Power ISO CE
Fully Pipe Bending Machine Price Of Indution Pipe Bending Machine
Production range:OD60mm-2000mm(2-80inches)
Radius:2.5 D ≤ R ≤ 10D ≤ 15000mm.
Thickness:2-90mm.
Angle:0-180 degree
Bending material: Carbon steel, alloy steel, stainless steel.
Operate way: Manual, PLC.
Main model and main technical parameters:
| Max size | Model | Heating power | Cylinder capacity | Thickness |
| 6” | HYG-159 | 200KW | IDΦ140 ODΦ168 | 5-20 |
| 8” | HYG-219 | 200KW | IDΦ140 ODΦ168 | 5-20 |
| 12” | HYG-325 | 250KW | IDΦ180 ODΦ219 | 5-20 |
| 16” | HYG-426 | 350KW | IDΦ180 ODΦ219 | 5-20 |
| 20” | HYG-530 | 400KW | IDΦ180 ODΦ219 | 5-20 |
| 24” | HYG-630 | 500KW | IDΦ200 ODΦ245 | 5-20 |
| 28” | HYG-720 | 600KW | IDΦ200 ODΦ245 | 5-20 |
| 32” | HYG-813 | 800KW | IDΦ220 ODΦ273 | 5-20 |
| 36” | HYG-914 | 800KW | IDΦ250 ODΦ299 | 5-20 |
| 48” | HYG-1220 | 1000KW | IDΦ280 ODΦ325 | 5-20 |
| 56” | HYG-1420 | 1000KW | IDΦ280 ODΦ325 | 5-20 |
| 60” | HYG-1520 | 1000KW | IDΦ280 ODΦ325 | 5-20 |
| 64” | HYG-1620 | 1000KW | IDΦ320 ODΦ377 | 5-20 |
The Fully Pipe Bending Machine Price Of Indution Pipe Bending Machine is suitable for oil, natural gas, chemical, electric power, construction and other industries.
The bending machine principle adopt induction heating and hydraulic cylinder pushing.
The material of the pipe: carbon steel, alloy steel, stainless steel, etc.
It is used for hot bending of various round steel pipe or square steel pipes, angle iron, channel steel and I-beam.
Steel pipe diameter range.
Steel pipe wall thickness range.
The numerous advantages of the Fully Pipe Bending Machine Price Of Indution Pipe Bending Machine bending process are now widely recognised and deployed across a diverse range of industries.
Induction bent pipes and tubes are typically used for anything from a large scale conduit to heat exchange and movement of a plethora of liquids and gases.
Bending by Heiyan for structural applications meets N.S.S.S tolerances and conforms to ASME standards for petrochemical applications.
This remarkable application flexibility means that we are able to provide a full service to a wide range of industries, including (but not limited to): -
The numerous advantages of the induction bending process are now widely recognised and deployed across a diverse range of industries.
Induction bent pipes and tubes are typically used for anything from a large scale conduit to heat exchange and movement of a plethora of liquids and gases.
Bending by Heiyan for structural applications meets N.S.S.S tolerances and conforms to ASME standards for petrochemical applications.
This remarkable application flexibility means that we are able to provide a full service to a wide range of industries, including (but not limited to): -
The bending radius is generally 2.5D--6D. Any large radius can be bend according to customer needs. Also can produce steel pipes with multiple curvature radius.
The bending angle is generally 0-90° or 0-180°
Equipment structure,
Induction heating power supply part including induction heating power supply, cooling water circulation system, operation cabinet (touch screen, PLC control system).
Hydraulic system: oil tank, pump station, hydraulic cylinder, oil pipe.
Mechanical body: hydraulic cylinder support , push plate, Chassis, platform, transformer support, slide rail, rocker spindle, clamp, etc.
