Copper Tube Aluminum Fin Tub Heat Exchanger , Home Portable AC Heat Exchanger
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
20-25days
Brand:
OEM
Product Description
Copper Tube Aluminum Fin Tube Heat Exchanger , Home Portable AC Heat Exchanger
Specification
| Tube Size | Fin (OD) | Fin Height | Fin Thickness | Fins Distance |
| Φ18x2 mm | Φ38 mm | 10 mm | 0.3 mm | 4-5 mm |
| Φ21x2 mm | Φ45 mm | 12 mm | 0.3 mm | 5-8 mm |
| Φ21x2 mm | Φ51 mm | 15 mm | 0.3 mm | 5-8 mm |
| Φ25x2 mm | Φ50 mm | 12.5 mm | 0.3 mm | 5-8 mm |
| Φ25x2 mm | Φ55 mm | 15 mm | 0.3 mm | 5-8 mm |
| Φ32x3 mm | Φ62 mm | 15 mm | 0.3 mm | 8-10 mm |
|
Other finned tube size can be customized. (Materials S/S 201, S/S 304, S/S 316 are optional) |
||||
- Materials of the heat exchanger
- Tube Φ9.52(3/8”), Φ12.7(1/2”), Φ15.88(5/8”),
- Wall thickness: smooth tube t0.30/0.41/0.50; inner grooved:
Φ9.52(3/8”)t (0.27+0.16)& t (0.30+0.17)/ Φ12.7(1/2”)& Φ15.88(5/8”)t (0.40+0.25)
- Fins: Aluminum, bare or hydrophilic coated, t0.15～0.30; Copper t0.12～0.30
- Fin pitch: Φ9.52 (3/8”) and Φ12.7 (1/2”)tube, F.P1.8～6.35mm; Φ15.88 (5/8”) F.P2.5～12.0mm
- Fin shape: surface sine wave/V-wave/Plat, edge shape: straight or Corrugated Wave
- Metal sheet: Galvanized steel plate, Al alloy plate, Stainless steel plate
- Surface: bare fin/blue hydrophilic coated fin/black E-coated fin, metal sheet with Epoxy powder coating.
- More details according to the drawing or specifics of customer.
Specification and function of the heat exchanger
- Fin die specifics of the products refer to sheet1-1.
- Dimension of the coils: Lmax10m*Hmax2.0m, it can be customized accordingly.
- Leakage test pressure≥3.0 MPa, Burst pressure≥10.0Mpa
- Cooling capacity: 5～500KW, it can be customized accordingly.
