Regenerator / Cooler Heat Exchangerfor , Tube Coil Heat Exchanger For CO2 Heat Pump Air
Tube coil heat exchanger is used for Cooler or regenerator for CO2 heat pump air
Overview
Liquid Flow Rate:4.5m3/h
Maximum Working Pressure:2.0Mpa
Weight:18kg, 18kg
Warranty:1 year
Applicable Industries:Hotels, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Restaurant, chemical industry
Condition:New
Tube material:SS304/SS316/SS316L/Carbon Steel/Cast Iron
Medium:Steam - Air
Feature:High Heat Transfer
Usage:Evaporative Air Cooling System
connection Material:Copper
Heat exchanger type:Tube Heater Exchanger
Application
1. Heat pump water heater condenser
2. Condenser/evaporator for aquarium or aquaculture water chiller
3. Condenser for pool heat pump
4. Condenser/evaporator for water(ground) source heat pump
5. Cooler or regenerator for CO2 heat pump air
6. Condenser/evaporator for marine AC
7. Condenser for ice machine
8. Evaporator for water purifier
9. Evaporation or condenser for mariculture constant temperature machine
10. Condenser for dish washer
11. Condenser/evaporator for industrial chillers.
12. Condenser/evaporator for chemical industrial cooling system.
13. Condenser/evaporator for marine or sea oil heat exchanger.
Detail parameters
| Model | HE-CT-010CA | HE-CT-015CA | HE-CT-020CA |
| Heat exchanger power | 10HP | 15HP | 20HP |
| Cooling capacity | 35kw | 52.5KW | 70KW |
| Heating capacity | 50kw | 75KW | 100 |
| Media inlet diameter(mm) | 25 copper | 25 | 25 |
| Media outlet diameter(mm) | 32 copper | 32 | 38 |
| Tube material | Stainless steel 304 | Stainless steel 304 | Stainless steel 304 |
| Tube diameter*thickness*length(mm) | 19*0.7*40000 | 19*0.7*60000 | 19*0.7*80000 |
| Diameter K(mm) | 300 | 350 | 400 |
| Dimension L(mm) | 250 | 300 | 350 |
| Diameter M(mm) | 200 | 250 | 300 |
| Diameter N(mm) | 150 | 200 | 250 |
| Weight (kg) | 18kg | 22kg | 28kg |
| Note:The above parameters are based on our regular products. Aidear can design heat exchangers that fully meet customer needs according to the size of the water tank, heating power, refrigeration power, connection specifications of water chillers, etc. | |||
Supply Ability
Supply Ability:10000 Set/Sets per Month
Packaging & Delivery
Selling Units:Single item
Single package size: 15X43X43 cm
Single gross weight:0.621 kg
Package Type:Wooden package.
- Support Sea freight
-
Quantity(Units) 1 - 3000 >3000 Est. Time(days) 14 Negotiable
