ROHS 2.0Mpa Finned Tube Heat Exchanger 50kw Thermal Capacity
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
3-15 days for 1-5 sets
Brand:
OEM/ODM
Product Description
ROHS 2.0Mpa Finned Tube Heat Exchanger 50kw Thermal Capacity
Specification
| Copper tube |
Die specific mm(inch) |
Fin shape |
Fin pitch (mm) |
Rows | Material | ||
| surface | Edge | Tube | Fins | ||||
| Φ5(1/5”) | 19.5*11.6 (0.768’’*0.457’’) | Louvered/V-wave | straight | 1.1-1.8 | 1-4 | copper | Al |
|
Φ7 (0.276”) |
21*12.7 (0.827’’*0.5’’) | Slit/louvered | straight | 1.2-2.0 | 1-4 | copper | Al |
| 21*18.3 (0.827’’*0.72’’) | V-wave/plat | Straight/waved | 1.2-3.0 | 1-4 | copper | Al | |
|
Φ7.94 (5/16”) |
22*19.05 (0.866’’*0.75”) | Louvered/waved/plat | Straight | 1.2-3.0 | 1-4 | copper | Al |
| 25.4*19.05 (1”*0.75”) | Louvered/waved/plat | straight | 1.3-4.0 | 1-6 | copper | Al | |
| 25.4*15.88 (1”*0.625”) | waved/plat | Straight/waved | 1.3-4.0 | 1-6 | copper | Al | |
| 25.4*22 (1”*0.866”) | Louvered/waved/plat | straight | 1.3-4.0 | 1-4 | copper | Al | |
| 30*30 (1.18”*1.18”) | Corrugated Wave | straight | 4.0-5.0 | 1-6 | copper | Al | |
|
Φ9.52 (3/8”) |
25*21.65 (0.984”*0.852”) | S-V/V-W/louvered/plat | Straight/waved | 1.5-3.2 | 1-12 | copper | Al |
| 25*21.65 (0.984”*0.852”) | S-W/plat | Straight/waved | 1.8-7.0 | 1-12 | copper | Al/SS | |
| 25.4*22 (1”*0.866”) | Louvered/waved/plat | Straight/waved | 1.5-3.2 | 1-12 | copper | Al | |
| 25.4*22 (1”*0.866”) | Plat/waved | Straight/waved | 3.2-6.35 | 1-12 | copper | Al | |
| 25.4*15.88 (1”*0.625”) | Waved/plat | Straight/waved | 1.3-4.0 | 1-12 | copper | Al | |
| 25.4*25.4 (1”*1”) | Plat | Straight | 3.2-6.35 | 1-12 | copper | Al | |
| 31.75*27.5 (1.25”*1.083”) | V-W/plat | Straight | 3.2-6.35 | 1-12 | copper | Al | |
|
Φ12.7 (1/2“) |
31.75*27.5 (1.25”*1.083”) | S-W/plat | Straight | 1.8-6.35 | 1-12 | Copper/SS | Al/T2/SS |
| 38.1*38.1 (1.50“*1.50“) | S-W/plat | Straight | 4.0-6.35 | 1-6 | Copper/SS | Al/T2/SS | |
| Φ12.0 | 48*41.75 (1.890“*1.637“) | V-W/plat | straight | 4.5-8.5 | 1-8 | copper | Al |
| 50*25 (1.969“*0.984“) | S-W/plat | straight | 4.0-7.0 | 1-12 | copper | Al | |
|
Φ15.88 (5/8”) |
38.1*33 (1.50”*1.299”) | Sine Wave/plat | straight | 2.2-5.0 | 1-6 | Copper/SS | Al/T2/SS |
| 38.1*33 (1.50”*1.299”) | Sine Wave | straight | 4.5-10.0 | 1-6 | Copper/SS | Al/T2/SS | |
| 38.1*38.1 (1.5”*1.5”) | Sine Wave | straight | 4.5-6.35 | 1-6 | Copper/SS | Al/T2/SS | |
| 50*50 (1.969”*1.969”) | Corrugated Wave | straight | 2.5-12.0 | 1-6 | Copper/SS | Al/T2/SS | |
| 60*52 (2.362*2.047”) | Corrugated Wave | straight | 4.5-10.0 | 1-6 | copper | Al | |
| 60*30 (2.362”*1.181”) | Corrugated Wave | straight | 2.6-8.5 | 1-8 | copper | Al | |
| 52*45 (2.047”*1.772”) | Corrugated Wave | straight | 6.0-12.0 | 1-6 | copper | Al | |
| Φ20 | 60*52 (2.362”*2.047”) | Corrugated Wave | straight | 4.5-12.0 | 1-6 | copper | Al |
Company information
Changzhou Aidear Refrigeration Technology Co.,ltd.Based on Honesty,Responsible,Technology and continuous Innovation.We are professional refrigeration system solutions provider. Main products are tube&fin heat exchangers,Microchannel heat exchanger,air cooler,condenser and units,raw materials and the components for heat exchangers,automatic machines for heat exchangers,and the complete solutions for customer. Welcome to contact us if you are intrested to our products or any question.
