China Elctronic Instruments High Voltage Silicon Wire With High Temperature Resistance for sale

Elctronic Instruments High Voltage Silicon Wire With High Temperature Resistance

Price Negotiable

Price: 0.2USD/M

MOQ: 6100 meters

Delivery Time: 10 days

Brand: YANGDA

Product Description

Low cost 3/5/10/15/20/25/30/50/100KV silicone high voltage wire

Product Type: AGG
Properties:
1. Rated Voltage: 3/5/10/15/20/25/30/50/100KV
2. Rated Temperature: -60°C~200°C
3. Conductor: Strand Tinned Copper
4. Insulation: Silicone Rubber
5. Color: Customized

It has good capacities of high-voltage cabinet, power systems, high voltage electric machineries, television receivers, transforms, high-voltage cabie for elctronic instruments, etc.

			Conductor

			Insulator

			Electrical Characteristic

			Cross Section

			Conductor Construction

			Diameter

			Insulator Thickness

			Over Diameter

			Realst.max
Cuc,c20℃

			mm2

			No.xΦmm

			mm

			mm

			mm

			Ω/km

			0.014

			7x0.05

			0.15

			0.15

			0.45

			1343

			0.035

			7x0.08

			0.24

			0.15

			0.54

			525

			0.05

			7x0.10

			0.3

			0.15

			0.6

			376.2

			1x0.26

			0.26

			0.17

			0.6

			376.2

			0.07

			1x0.30

			0.3

			0.2

			0.7

			245

			0.08

			7x0.12

			0.36

			0.2

			0.76

			227

			0.12

			7x0.15

			0.45

			0.2

			0.85

			150

			0.2

			7x0.20

			0.6

			0.25

			1.1

			83.5

			0.35

			19x0.16

			0.8

			0.25

			1.3

			49.5

			0.5

			19x0.18

			0.9

			0.25

			1.4

			36

			0.75

			19x0.23

			1.15

			0.275

			1.7

			22.7

			1

			19x0.26

			1.3

			0.25

			1.8

			19

			1.2

			19x0.28

			1.4

			0.3

			2

			15.3

			1.5

			19x0.32

			1.6

			0.3

			2.2

			11.7

			2

			19x0.37

			1.85

			0.3

			2.45

			9.45

			2.5

			19x0.41

			2.05

			0.4

			2.85

			6.86

			4

			37x0.37

			2.59

			0.4

			3.38

			4.51

			6

			37x0.45

			3.15

			0.5

			4.2

			3.05

600V Copper Conductor PVC Insulated Electrical Power Cables

0.5mm2 600V Insulated Wire With Tinned Copper Conductor

24AWG 0.5mm Insulated Wire With DIN Bobbin

300V FEP Insulated Carbon Fiber Heating Wire For Home Appliances

UL10064 32AWG Micro High Temperature Stranded Wire

30AWG 300V PVC Insulated Wire For Electric Equipment

UL1015 450V 750V 3mm PVC Insulated Electrical Cable Wire

Copper Conductor PVC Insulated Low Voltage Wire For Car

2.5mm PVC Insulated Copper Core BV Electric Wire Cable For Factory

UL1015 450 750V PVC Insulated Stranded Nylon Wire

3 Pin US Standard Power Cord For Stage Light Power Plug

IEC60502 American Standard PVC Power Cord Wire

Get in Touch

Have questions about our products or want to discuss a custom order? Our team is ready to help you.

Company Dongguan city yangda Electronic Co., Ltd

Location Chang'an Town, Dongguan City, Guangdong Province, China

Request A Quote

Email Address *

Please check your email address.

Phone / WhatsApp

Your Message *

Your message must be at least 20 characters.

Conductor			Insulator		Electrical Characteristic
Cross Section	Conductor Construction	Diameter	Insulator Thickness	Over Diameter	Realst.max Cuc,c20℃
mm2	No.xΦmm	mm	mm	mm	Ω/km
0.014	7x0.05	0.15	0.15	0.45	1343
0.035	7x0.08	0.24	0.15	0.54	525
0.05	7x0.10	0.3	0.15	0.6	376.2
0.05	1x0.26	0.26	0.17	0.6	376.2
0.07	1x0.30	0.3	0.2	0.7	245
0.08	7x0.12	0.36	0.2	0.76	227
0.12	7x0.15	0.45	0.2	0.85	150
0.2	7x0.20	0.6	0.25	1.1	83.5
0.35	19x0.16	0.8	0.25	1.3	49.5
0.5	19x0.18	0.9	0.25	1.4	36
0.75	19x0.23	1.15	0.275	1.7	22.7
1	19x0.26	1.3	0.25	1.8	19
1.2	19x0.28	1.4	0.3	2	15.3
1.5	19x0.32	1.6	0.3	2.2	11.7
2	19x0.37	1.85	0.3	2.45	9.45
2.5	19x0.41	2.05	0.4	2.85	6.86
4	37x0.37	2.59	0.4	3.38	4.51
6	37x0.45	3.15	0.5	4.2	3.05
