ul factory Awm Ul1061 sr-pvc insulated and tinned copper stranded heat resistant wire cable
Price:
0.15USD/M
MOQ:
6100M
Delivery Time:
7DAYS
Brand:
YANGDA
Product Description
Ul Factory Awm Ul1061 Sr-Pvc Insulated And Tinned Copper Stranded Heat Resistant Wire Cable
All our wires and cables are made of 99.99% pure oxygen free copper and high quality PVC which comply with the European UnionRoHS environmental protection instruction.
1.Rated temperature:80ºC
2.Rated voltage:300v
3.according to:UL subject 758,UL1581
4.Solid or Stranded,tinned or bare copper conductor 30-16AWG
5.SR-PVC insulation.
6.Passes UL VW-1 & CSA FT1 Vertical flame test
7.uniform insulation thickness of wire to ensure easy stripping and cutting
8.Environmental testing pass ROHS
Product Parameters
| UL Style | conductor | Overall Diameter(mm) | Insulation Thickness(mm) | wire O.D(mm) | Max Cond.resistance(Ω/kft) | Standard length | ||
| (AWG) | (no/mm) | FT/ROLL | METER/ROLL | |||||
| UL1061 | 30 | 7/0.10 | 0.3 | 0.23 | 0.8 | 116 | 2000 | 610 |
| 28 | 7/0.127 | 0.38 | 0.9 | 72.8 | ||||
| 26 | 7/0.16 | 0.48 | 1 | 45.8 | ||||
| 24 | 11/0.16 | 0.61 | 1.1 | 28.7 | ||||
| 22 | 17/0.16 | 0.76 | 1.3 | 18.1 | ||||
| 20 | 21/0.178 | 0.94 | 1.5 | 11.2 | ||||
| 18 | 16/0.254 | 1.16 | 1.8 | 7.06 | ||||
| 16 | 26/0.254 | 1.49 | 2.1 | 4.45 |
||||
