10 Tons Truss Type Double Girder Gantry Crane For Grabing Sand
10 tons truss type double beam mobile rail grab gantry crane for grabing sand
1. Some description
10 tons truss type double beam mobile rail grab gantry crane for grabing sand is usually used in open-air warehouses or along railways. His control method is usually the cab or ground control. The appearance is in the shape of "A". The cab control box-type double-beam track walking grab or bucket portal crane is suitable for the transportation of ore, limestone, powdered ore, coke, coal, etc. Sand and other bulk particles are placed indoors or in the open air and between fixed spans. The grab is more suitable for bulk materials under natural accumulation.
2. Some Specification
| Lifting capacity | t | 10 |
| Span | m | 25 |
| Lifing height | m | 10 meters above the track, 10 meters below the track |
| Lift and close speed | m/min | 40.92/40.92 |
| Handcart travelling speed | m/min | 49.6 |
| Crane travelling speed | m/min | 39.7 |
| Total weight of crane | t | 116.5 |
| Max. wheel presure for crane | kN | 22.7 |
| Max. height for coal bogie | mm | 5000 |
| Left arm length | mm | 9850 |
| Right arm length | mm | 10450 |
Main feature:
1. Heavy duty double beam/girder gantry with grab as lifting tool.
2. Working duty could be A6-A8.
3. Soft start, 3-5 speeds to operate, very stable to lift and running.
4. Six direction action, to make sure the enough wide working area.
5. Strong box type steel structure of crane
6. Full safety system as follows:
Weight overload protection
Emergency stop system
Over current protection,Short-circuit protection
Phase sequence protection
Zero position protection
Voltage loss protection
crane long traveling and cross traveling limit switch and stopper
Lifting overhigh and overlow limit switch
3. FAQ:
Q1 . What do Henan Mine Crane do ?
A1: We design, produce, install overhead crane, gantry crane, port crane, hoists, winch and so on.
Q2 . What makes you different from other manufacturers ?
A: We have trained service technicians who will be able to get your materical equipment up and running, and have been prodiding our customers an effective service solution.
Q3: What projects do you have regarding this type of crane?
A: Our cranes used in the port of Krasnodar, Russia. In addition, our engineers overcome the local low temperature conditions of minus 40 degrees when designing the crane.
Q4: Can you provide installation?
A: If you need , we can send engineers where you need them.
