China 380V Battery Production Equipment Square Battery Fully Automatic Packaging Line for sale

380V Battery Production Equipment Square Battery Fully Automatic Packaging Line

Price Negotiable

Price: Negotiation, email communication

MOQ: 1

Delivery Time: 90 Working day

Brand: ZeCheng

Product Description

Battery Production Equipment Square Wireless Headphones polymer battery fully automatic packaging line

1.The profile

This equipment is mainly after the winding square batteries or laminated rectangular batteries for pressing, rolling, aluminum-plastic film automatic automatic correction automatic fixed-length cutting, automatic punching hole forming, batteries, automatic feeding, automatic short circuit test, automatic into the shell, aluminum-plastic film automatic folding, automatic sealing, automatic side sealing, HI - POT test automatically, automatic trimming, automatic coating, automatic blanking.

Features: 1.1the whole packaging line has a high degree of automation. It is enough to manually put the whole battery into the feeding station after winding. 1.2 high efficiency: 15PPM 1.3 automatic short-circuit testing: automatic testing of hi-pot, and automatic elimination of unqualified. 1.4 low operation cost: the equipment has a high degree of automation and is easy to operate manually. A worker can operate several devices at the same time.2.1.2 adapt to raw material specifications

Material	Feed way	Material sheet length(mm)	Material width (mm)		The thickness of the material(μm)		Largest diameter(mm)	The inner diameter(mm)
Material	Feed way	Size range	Size range	tolerance	Size range	The tolerance	Largest diameter(mm)	The inner diameter(mm)
Aluminium plastic film	coil	coil	150-300	0.2	100-200	5	ф400	ф76.2

2.1.3.1 adaptive objectsThe battery size

Model	W (mm)	L(mm)	H (mm)
ZLA01A	20-50	20-50	2-8

2.1.4 equipment technical parameters

Item	specifications	ZLA01A
Technical parameters	Efficiency(PPM)	15
	Pressure(T)	3
	Temperature control accuracy	+/-1℃
	Edge width	3-10mm
	Encapsulation time range	3-6S
	Sealing side thickness	0.19-0.3mm(Can be set)
	Temperature setting	180°adjustable
	Precision of automatic forming outline size	±0.2mm
	Hole depth accuracy	±0.1mm
	Upper and lower film alignment	小于0.3mm
	Maximum pressure	3T(The pressure is adjustable)
	Press mold to ensure the normal service life	More than a million times
	Compressed air system	Air source provided by party a
	The total power(kw)	18
	Normal operating power(kw)	15
	Qualified rate of equipment products	≥95% (A bad product caused only by the machine)
	Equipment failure rate	≤5%(Failure caused by equipment only)
