OEM Aluminum Forming Die Deep Drawn Metal Stamping

Customized for aluminum forming die deep drawing metal stamping

Deep-drawing metal stamping is a metal stamping process that is mainly used to form various hollow axisymmetric components from metal plates. This form of metal stamping involves applying a punching force to the metal plate so that it is drawn into the cavity in the radial direction.

1. First, place the metal plate on the forming mold. The paper is fixed at the end by the pressure exerted by the blank holder.

2. Then, the axial force is applied to the metal plate by a mechanical stamping tool to deform the workpiece and flow into the mold cavity to produce the desired shape.

Advantages of deep drawing metal stamping

Almost all manufacturing industries have the potential to benefit from the deep drawing manufacturing process. This technology may be most useful for manufacturing small stamped parts such as electronic caps, housings, and component housings. However, products of various shapes and sizes can be economically produced through this process, including items such as aluminum cans, cookware and kitchen sinks. In mass production, deep drawing is particularly advantageous because as the number of units increases, the unit cost will be greatly reduced: once the mold is created, the mold production process can continue with little downtime or maintenance time.

Deep drawing metal stamping parameters
