Pelton Turbine Generator

Pelton turbine is a type of turbine used frequently in hydroelectric plants. These turbines are used for sites with high head.

When used for generating electricity, there is usually a water reservoir located at some height above the Pelton turbine. The water then flows through the penstock to specialized nozzles that introduce pressurized water to the turbine. To prevent irregularities in pressure, the penstock is fitted with a surge tank that absorbs sudden fluctuations in water that could alter the pressure.

Hydro turbine generator is droved directly or indirectly by hydro turbine. The rotating speed is less than 1500r/min, with horizontal and vertical arrangement. Excitation mode with brushless and static silicon type.

1. Product Paramenters

Please can you send me below parameters, so our engineers could support your project?

Where is the plant?

1.Design head: ___m

2.Design flow: ___m?/s

3.Frequency: 50Hz or 60Hz?

4. Unit Capacity: ___KW；How many kw each unit? How many units?

5. Power factor COSφ:

6.Generator output voltage: __V

7.On-grid or Off-grid type? (On-grid type voltage: ____Kv)

8. M.a.s.l: ___ m

9.Basic situation about the project and your company introduction.

So I can choose the model for you and send you pictures.

Friendly reminder: The price of this product is not the actual price, because our products are non-standard customized, please contact customer service to provide the water head and flow rate, select the model on-site quotation, and then place the order. Welcome to visit, thank you!
