Full Color CCD Color Sorter High Accuracy With LCD Touch Screen Interface
Full Color CCD Rice Color Sorter
Full Color CCD Rice Color Sorter is the high-end product which has remote control AI system and IR filter shifting system
If you are looking for the range of rice color sorter machines, then look no further. We are an famous manufacturer, exporter, trader and supplier of these Rice Color Sorter machines for all types of rice like double boiled, ponni, raw, half boiled, deluxe, and basmati. The standard features of this machine are LCD touch screen interface, superior performance chutes, self tuning vibrator, and mild steel ejector valves. Our provided Rice Color Sorter is in high demand as in the market, premium quality grains are the only need and consumers are willing to pay extra for best quality.
Technical Parameters
| Model |
Capacity (T/H) |
Carryover (Bad:Good) |
Accuracy (%) |
Voltage (V/HZ) |
Power (KW) |
Weight (KGS) |
Dimension (MM) |
| RZ1 | 1-2 | 80:1 | >99.9 | 220/50 | 0.5-0.8 | 270 | 875x1550x1320 |
| RZ2 | 1.5-3 | 80:1 | >99.9 | 220/50 | 0.65-1.1 | 460 | 1240x1710x1720 |
| RZ3 | 2-4 | 80:1 | >99.9 | 220/50 | 0.85-1.4 | 650 | 1555x1710x1720 |
| RZ4 | 3-6 | 80:1 | >99.9 | 220/50 | 1-1.8 | 840 | 1870x1710x1720 |
| RZ5 | 4-8 | 80:1 | >99.9 | 220/50 | 1.3-2.2 | 1030 | 2185x1710x1720 |
| RZ6 | 4.5-9 | 80:1 | >99.9 | 220/50 | 1.7-2.8 | 1220 | 2500x1710x1720 |
| RZ7 | 5-10 | 80:1 | >99.9 | 220/50 | 1.9-3.2 | 1350 | 2815x1710x1720 |
| RZ8 | 6-12 | 80:1 | >99.9 | 220/50 | 2.2-3.7 | 1510 | 3130x1710x1740 |
| RZ10 | 7-16 | 80:1 | >99.9 | 220/50 | 2.5-4.2 | 1850 | 3760x1710x1740 |
| RZ12 | 9-18 | 80:1 | >99.9 | 220/50 | 2.9-4.8 | 2190 | 3935x1710x1740 |
Remarks: The above parameters are tested results based on Polished round rice with the single chute 1-3T/H capacity. Actual capacity may vary according to raw material contamination ratio.
Examples of Sorting
Product Advantages
* Big Database
* Automatic Computing and Super Brain Intelligent Identification
* 5400Pixel CCD Image Acquisition System
* Image Processing System
* Intelligent Dust Cleaning System
* Self Design High Frequency Ejectors
* Low Temperature LED Light Source
* Intelligent LED Control System
* Remote Control System
* IR filter shifting system
Why Choose Our Rice Color Sorter?
1) Designed and manufactured by a major Chinese color sorter company who has been devoted in color sorter Manufacture for over 10 years, the technology is mature and the machine is long time tested by the market.
2) Famous of high accuracy and persistence.
- All our machines can be customized, including Italian matrix ejectors, Japanese SMC ejectors, Japanese Nikon cameras, etc.
- OEM is available for all of our machines.
- Engineers available to provide installation and after sale service in all countries.
Get in Touch
Have questions about our products or want to discuss a custom order? Our team is ready to help you.
