High Efficiency Coffee Bean Color Sorter For Food Processing Industry
Coffee Bean Color Sorter Machine
Product Description
CCD coffee bean color sorter machine is ideal for sorting Arabica coffee beans, removing a variety of defects to increase product quality and safety.By incorporating the latest technological advances, defects such as sticks, stones, odd colors beans and other foreign seeds can be removed effectively and efficiently.
Para defectos primarios, tenemos una eficiencia del 100% en eliminación de defectos graves o
granos completamente manchados (negros y rojos)
Technical Parameters
| Model | Capacity(bad:good) | Accuracy(%) | Power(v/Hz) | Voltage(Kw) | Weight(Kg) | Dimension(mm) |
| RC64 | ＞10:1 | ≥99.99% | AC220V/50HZ | 0.3~0.5 | 240 | 974.2*1550.9*1399 |
| RC128 | ＞10:1 | ≥99.99% | AC220V/50HZ | 0.3~0. 5 | 500 | 1239*1705.3*1827.9 |
| RC192 | ＞10:1 | ≥99.99% | AC220V/50HZ | 0.7-1.1 | 800 | 1554*1707*1827.9 |
| RC256 | ＞10:1 | ≥99.99% | AC220V/50HZ | 0.7-1.1 | 1000 | 1869*1707*1827.9 |
| RC320 | ＞10:1 | ≥99.99% | AC220V/50HZ | 0.7~1.1 | 1100 | 2184*1707*1827.9 |
| RC384 | ＞10:1 | ≥99.99% | AC220V/50HZ | 1.1~1.9 | 1350 | 2499.2*1707*1827.9 |
| RC448 | ＞10:1 | ≥99.99% | AC220V/50HZ | 1.1~1.9 | 1350 | 2814.2*1706.7*1839.9 |
| RC512 | ＞10:1 | ≥99.99% | AC220V/50HZ | 1.3~2.2 | 1500 | 3129*1709.9*1827.9 |
| RC640 | ＞10:1 | ≥99.99% | AC220V/50HZ | 1.4~2.3 | 1750 | 3759.2*1709.9*1827.9 |
| RC768 | ＞10:1 | ≥99.99% | AC220V/50HZ | 1.4-2.3 | 1900 | 4389.2*1709.9*1827.9 |
Remark: We have many models from 1 chute to 16 chutes for option to meet any different production capacity.The exact production capacity may change due to different impurity level.
Product Function & Features
Ejector
Independent developed intelligent magnetic control high-frequency ejector has no air leakage problem thanks to the replacement of intelligent lever flexible return technology for traditional pressure return technology.
Cloud Interconnection System
Thanks to AMD cloud service technical platform, remote control, operation, matainence, software upgrade can be achieved and it can detect and solve the LED light, electronical,mechanical and adjustment problems.It also can provide real-time online tracking service for the machine operation monitoring,data acquisition and online instruction.
One Key Intelligent Operation System
The users can set the area of the material color, shape, size and defect by themselves and confirm the rejected material, so the machine can automaticly set the sorting solution of the material according to the independent caculating, intelligent recognition and intelligent sorting principles with one key intelligent control technology.
Intelligent Visual Image Capture System
It can realize the visual dynamic image capture system by adopting the high resolution full color CCD sensor and begeye low distortion lens.
Inlelligent LED Light Control System
It can adjust the brightness of the LED automatically according to the material sorting requirements and enviroment changing due to advanced digital stepless automatic LED light adjustment technology. The best sorting performance will be achieved.
Examples of Sorting
