Smart Optical Sorting Machine With High Definition CCD Image Acquisition System
Price:
Negotiable
MOQ:
1set
Delivery Time:
15 days after we receive your deposit
Brand:
BANGHAO
Product Description
Channel Optical Color Sorter
Channel Optical Color Sorter Features
1. The introduction of LED air cooling.
2. The unique suction ventilation system.
3. Full-color high-definition CCD camera image acquisition system.
4. Intelligent operating platform, easy to operate, easy to master, the real man-machine dialogue, intelligent docking, sit back and relax.
5. International high-end full-color line scan technology.
Technology Data
| Model | RCSK2 | RCSK3 | RCSK4 | RCSK5 | RCSK6 | RCSK7 |
| Output(t/h) | 2-5 | 4-7.5 | 6-10 | 7-12.5 | 8-13 | 10-15 |
| Carryover (bad:good) | >8:1 | >8:1 | >8:1 | >8:1 | >8:1 | >8:1 |
| Accuary(%) | >99% | >99% | >99% | >99% | >99% | >99% |
| Power(V/Hz) | 220/50 | 220/50 | 220/50 | 220/50 | 220/50 | 220/50 |
| Power(Kw) | 0.8-1.5 | 1-2.0 | 1-3.0 | 1.5-3.5 | 1.5-4.0 | 2-4.5 |
| Air pressure(Mpa) | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 |
| Consumption(L/min) | ＜960 | ＜1440 | ＜1920 | ＜2400 | ＜2880 | ＜3360 |
| Weight(Kg) | 500 | 700 | 850 | 950 | 1100 | 1400 |
| Dimensions(mm) | 1250*1607*1953 | 1875*1607*1953 | 1920*1607*1953 | 2260*1607*1953 | 2596*1607*1953 | 2934*1607*1953 |
Recommended Applications
* Rice
* Wheat
* Peanuts
* Seeds
* Grains
* Beans and Pulses
Example of Sorting
