Intelligent Full Color CCD Color Sorter Machine 2 Chutes Optical Color Sorter
Intelligent Full Color CCD Color Sorter Machine 2 Chutes Optical Color Sorter
Product Description
We are one of the biggest manufacturer of intelligent CCD 2 Chutes multi function color sorter in China. We manufacture many different type of sorter machines. The optical sorting range from mineral and plastic industry to food. The products include ore sorting machine, rice color sorter, coffee bean optical sorting machine, tea sorter and so on. Welcome your inquiry. We will offer you the most professional sorting solutions!
Technical Parameters
| Model | 6SXZ-68L | 6SXZ-68L | 6SXZ-136L | 6SXZ-272L |
| Output | <600kg/h | <1000kg/h | <1200kg/h | <2400kg/h |
| Carry over Rate(Bad:Good) | 12.5:1 | 12.5:1 | 12.5:1 | 12.5:1 |
| Sorting Accuracy | ≥99.9% | ≥99.9% | ≥99.9% | ≥99.9% |
| Voltage(V/Hz) | 220V 50HZ | 220V 50HZ | 220V 50HZ | 220V 50HZ |
| Power Supply(Kw) | 0.7-1.0 | 1.5-2.0 | 1.5-1.8 | 2.5-3.0 |
| Pressure(Mpa) | 0.4-0.6 | 0.4-0.6 | 0.5-0.7 | 0.6-0.8 |
| Air Consumption(L/min) | <500 | <600 | <1000 | <2000 |
| Weight | 310kg | 550kg | 490kg | 920kg |
| Dimension | 2051*1240*1762mm | 3200*2020*810mm | 2037*1540*1550mm | 1922*2430*1349mm |
Examples of Sorting
Product Advantages
1. Linear array CCD full color sorting technology, high resolution identification, high speed sorting and more precise identification.
2. Visible full-color spectral distribution, free to adjust the spectral region.
3. Supports synchronized multi-tasking, various modes of color sorting, supports sorting, resorting, a variety of colors synchronized sorting, the yellow film in the tea, white, black,tea stalk and other sorting at the same time.
4. Integrates shape difference technology, improving the accuracy of tea leaves sorting quality.
5. Overcomes problems of current technology, such as Tieguanyin sorting, etc. Achieving an intelligent and mechanized sorting.
6. Powerful intelligent software operating platform, easy to learn and use, suitable for all levels of personnel operations.
7. Exclusive Color and Shape Sorting mode, to achieve a better performance when differenciating the color of tea, twisted tea and leaf foliage, improving sorting performance.
8. Mini Tea Color Sorter has small size, large output, about 100kg per hour, suitable for home or small and medium-sized tea processing plants.
Products Show
Working Principle
According to the difference in the color of the material, the equipment that automatically sorts the different-colored particles in the granular material.
Why Chose Our Tea Color Sorting Machine?
1. Over 14 years experiences.focus on sorter machine.The biggest sorter machine factory.
2. After-sales service guarantee: We have a professional after-sales service team, one-on-one customer service to help customers install and repair.
3. We have service station, cooperate reseller in more than 40 countries.
4. Quality assurance of raw materials:The raw materials we purchase are certified qualified products.
5. Quality process assurance: We pass ISO quality management system, each process of production are under strictly standard.
6. System test: Our technical engineers check the product performance, to ensure that the factory products in full compliance with customer requirements.
7. Shipping guarantee: we have professional packaging operations team, independent export qualification to ensure product safety and stability to reach customers in the hands.
