Custom Vmax 5-10 Ton Diesel Powered Forklift 3000mm Mast Lifting Height
Price:
Negotiable
MOQ:
1UNIT
Delivery Time:
45 DAYS
Brand:
VMAX
Product Description
Custom Vmax 5-10 Ton Diesel Powered Forklift 3000mm Mast Lifting Height
| 8-10T COUNTER BALANCE DIESEL FORKLIFT TRUCK SPECIFICATION | ||||
| Model | Unit | CPCD80 | CPCD100 | |
| Power type | Diesel | |||
| Rated capacity | kg | 8000 | 10000 | |
| Load center | mm | 600 | ||
| Mast Lifting height | mm | 3000 | ||
| Free lift height | mm | 205 | 210 | |
| Fork size(L*W*T) | mm | 1220×170×70 | 1220×170×80 | |
| Tilting Angles(Front/Rear) | deg | 6°/12° | ||
| Front overhang | mm | 620 | 718 | |
Exterior Size |
Length without fork | mm | 3633 | 4260 |
| Overall width | mm | 1995 | 2245 | |
| Mast drop | mm | 2700 | 2850 | |
| Max.lift | mm | 4420 | 4325 | |
| Front-wheel Overhead | mm | 2450 | 2585 | |
| Min Turning Radius | mm | 3400 | 3900 | |
| Min.intersecting aisle | mm | 3310 | 3540 | |
Speeds |
Max Driving speeds | km/h | 26/30 | |
| Lifting speeds | mm/s | 440/470 | 360/380 | |
| Lowering speeds | mm/s | ≤600 | ||
| Max.grade ability | % | 27 | 22 | |
| Total weight | kg | 10480 | 12460 | |
Tires |
Front | 8.52-15-14PR | 9.00-20-14PR | |
| Rear | 8.52-15-14PR | 9.00-20-14PR | ||
| Wheelbase | mm | 2250 | 2800 | |
Tread |
Front | mm | 1470 | 1600 |
| Rear | mm | 1700 | ||
| Min.ground clearance | mm | 250 | 245 | |
Engine |
Model | chaochai6102/xichai6110 | ||
| Rated output | kw/rpm | 37/2650 | ||
| Rated torque | N.m/rpm | 148/1800 | ||
| No.of cylinder | 6 | |||
| Displacement | L | 5.785 | ||
| Fuel tank capacity | L | 160 | ||
