Manual Operation Diesel Engine Forklift 4500kgs Loading Capacity 3105 * 2290 * 1480mm
Price:
＄13,870.00-＄18,500.00/unit
MOQ:
1 unit
Delivery Time:
25-30 days
Brand:
VMAX
Product Description
manual operation Japanese engine 4.5 ton diesel forklift with CE ISO90001 certificate:
| SPECIFICATIONS of VMAX diesel Forklift | ||||
| Manufacturer's Data and Desigh Characteristics | ||||
| Specifications | ||||
| 1 | Manufacturer | |||
| 2 | Model | Unit | CPC45 | |
| 3 | Power type | DIESEL | ||
| 4 | Rated capacity | kg | 4500 | |
| 5 | Load center | mm | 500 | |
| 6 | Operator type | |||
| Size | ||||
| 7 | Max. lift height of mast with Load-backrest | mm | 4280 | |
| 8 | Max.lift height of fork | mm | 3000 | |
| 9 | Height of mast | mm | 2330 | |
| 10 | Free lift height(with backrest) | mm | 150 | |
| 11 | Height of Load-backrest | mm | 1195 | |
| 12 | Distance from seat to overhead guard | mm | 1000 | |
| 13 | overhead guard height | mm | 2290 | |
| 14 | Length without fork | mm | 3105 | |
| 15 | Front overhang | mm | 565 | |
| 16 | Rear overhang | mm | 540 | |
| 17 | Wheel base | mm | 2000 | |
| 18 | The height of traction pin | mm | 350 | |
| 19 | Min. ground clearance | mm | 160 | |
| 20 | Overall width | mm | 1480 | |
| 21 | The distance between forks | mm | 1370/300 | |
| 22 | Tread(front /rear) | mm | 1180/1190 | |
| 23 | Min. Turning radius(outside) | mm | 2780 | |
| 24 | Min. Turning radius(inside) | mm | 270 | |
| 25 | Min. Intersecting aisle | mm | 3365 | |
| 26 | Mast tilt angle | deg | ||
| 27 | Fork size | mm | 1070*150*50 | |
| Performance | ||||
| 28 | Speeds |
Max.Drive speeds(with/without full load) | km/h | 18/19 |
| 29 | Lifting speeds (with /without full load) | mm/s | 400/450 | |
| 30 | Lowering speeds(with /without full load) | mm/s | 350/400 | |
| 31 | Max. tractive force(with /without full load) | KN | 20/19 | |
| 32 | Max.grade ability (with/without full load) | % | 18/20 | |
| Weight | ||||
| 33 | Total weight | kg | 6400 | |
| 34 | Weight Distribution full load (front/ rear) | kg | 9540/1360 | |
| 35 | Weight Distribution zero load(front / rear) | kg | 2630/3770 | |
| Wheels and Tyres | ||||
| 36 | Quantity of wheels | |||
| 37 | Type of tyres | |||
| 38 | Tires | Front | 300-15-18PR | |
| 39 | Rear | 7.00-12-12PR | ||
| 40 | Driving Brake | |||
| 41 | Parking Brake | |||
| Control device for driving and transmitting | ||||
| 42 | Battery | V/AH | (12/80)*2 | |
| 43 | Engine (standard) | Model | XINCHANG 4D35G | |
| 44 | Rated output | kw/rpm | 48/2200 | |
| 45 | Rated torque | N.m/rpm | 230/1600-1800 | |
| 46 | No.of cylinder | 4-98X105 | ||
| 47 | Displacement | L | 3.46 | |
| 48 | Fuel tank capacity | L | 80 | |
| 49 | Number of speeds for transmission | |||
