VMAX Diesel Powered Forklift CPCD50 Automatic Transmission With Optional Color
Price:
＄16,900.00-＄25,000.00/unit
MOQ:
1 unit
Delivery Time:
25-30 days
Brand:
VMAX
Product Description
best forklift brand VMAX diesel engine truck CPCD50 with optional color:
| SPECIFICATIONS of VMAX diesel Forklift | ||||
| Manufacturer's Data and Desigh Characteristics | ||||
| Specifications | ||||
| 1 | Manufacturer | |||
| 2 | Model | Unit | CPCD50 | |
| 3 | Power type | DIESEL | ||
| 4 | Rated capacity | kg | 5000 | |
| 5 | Load center | mm | 600 | |
| 6 | Operator type | |||
| Size | ||||
| 7 | Max. lift height of mast with Load-backrest | mm | 4380 | |
| 8 | Max.lift height of fork | mm | 3000 | |
| 9 | Height of mast | mm | 2500 | |
| 10 | Free lift height(with backrest) | mm | 205 | |
| 11 | Height of Load-backrest | mm | 1372 | |
| 12 | Distance from seat to overhead guard | mm | 1045 1045 1080 | |
| 13 | overhead guard height | mm | 2450 | |
| 14 | Length without fork | mm | 3440 | |
| 15 | Front overhang | mm | 590 | |
| 16 | Rear overhang | mm | 600 | |
| 17 | Wheel base | mm | 2250 | |
| 18 | The height of traction pin | mm | 395 | |
| 19 | Min. ground clearance | mm | 200 | |
| 20 | Overall width | mm | 1995 | |
| 21 | The distance between forks | mm | 1840/300 | |
| 22 | Tread(front /rear) | mm | 1470/1700 | |
| 23 | Min. Turning radius(outside) | mm | 3250 | |
| 24 | Min. Turning radius(inside) | mm | 210 | |
| 25 | Min. Intersecting aisle | mm | 2960 | |
| 26 | Mast tilt angle | deg | ||
| 27 | Fork size | mm | 1220*150*55 | |
| Performance | ||||
| 28 | Speeds |
Max.Drive speeds(with/without full load) | km/h | 26/28 |
| 29 | Lifting speeds (with /without full load) | mm/s | 510 | |
| 30 | Lowering speeds(with /without full load) | mm/s | 600/300 | |
| 31 | Max. tractive force(with /without full load) | KN | 65 | |
| 32 | Max.grade ability (with/without full load) | % | 35/18 | |
| Weight | ||||
| 33 | Total weight | kg | 8160 | |
| 34 | Weight Distribution full load (front/ rear) | kg | 11810/1350 | |
| 35 | Weight Distribution zero load(front / rear) | kg | 4100/4060 | |
| Wheels and Tyres | ||||
| 36 | Quantity of wheels | 4 X / 2 | ||
| 37 | Type of tyres | |||
| 38 | Tires | Front | 8.25-15-14PR | |
| 39 | Rear | 8.25-15-14PR | ||
| 40 | Driving Brake | |||
| 41 | Parking Brake | |||
| Control device for driving and transmitting | ||||
| 42 | Battery | V/AH | ||
| 43 | Engine (standard) | Model | XICHAI 6110 | |
| 44 | Rated output | kw/rpm | 83/2000 | |
| 45 | Rated torque | N.m/rpm | 450/1450 | |
| 46 | No.of cylinder | 6-100X125 | ||
| 47 | Displacement | L | 7.13 | |
| 48 | Fuel tank capacity | L | 140 | |
| 49 | Number of speeds for transmission | |||
MORE PHOTOS FROM OUR FACTORY:
