122mm Fork Width 1.8 Ton Electric Warehouse Forklift 6000mm Lifting Height
Price:
＄9,775.00-＄18,000.00/unit
MOQ:
1 unit
Delivery Time:
25-30 days
Brand:
VMAX
Product Description
1.8 ton electric forklift truck 6000mm lifting height optional colors Curtis:
| Main Information | |||
| 1.1 | Brand | VMAX | |
| 1.2 | Model | CPD18 | |
| 1.4 | Operation type | Drive in seat | |
| 1.5 | Load capacity | kg | 1800 |
| 1.6 | Load center | mm | 500 |
| 2.1 | Weight with battery | kg | 3200 |
| Tire,chassis | |||
| 3.1 | Tire Type,Driving wheel/Load wheel | ||
| 3.2 | Number of wheels X=driving wheel(front/behind) | ||
| 3.3 | Tire size (front/behind) | 7.00-12-12PR/18X7-8PR | |
| 3.4 | Service brake | ||
| 3.5 | Parking service | ||
| Size | |||
| 4.1 | Mast tilt,Forward/backward |
α/β(°) | 6/12 |
| 4.2 | Mast height after mast fall |
mm | 1995 |
| 4.3 | Fork lift max height | mm | 4025 |
| 4.4 | Free lift height | mm | 140 |
| 4.5 | Standard Mast height | mm | 3000 |
| 4.6 | Overhead guard height | mm | 2100 |
| 4.7 | Overall length | mm | 2035 |
| 4.8 | Fork overhang | mm | 400 |
| 4.9 | From the rear | mm | 335 |
| 4.10 | Wheelbase | mm | 1360 |
| 4.11 | Minimum distance between the ground | mm | 110 |
| 4.12 | Tread (front/behind) | mm | 912/920 |
| 4.13 | Vehicle width | mm | 1090 |
| 4.14 | Fork size | mm | 1070x122x45 |
| 4.15 | Channel width, |
mm | 3739 |
| 4.16 | Turning radius | mm | 1997 |
| Performance | |||
| 5.1 | Walking speed,loaded/withoutload |
km/h | 13/15 |
| 5.2 | lifting speed,loaded/load | m/s | 240/450 |
| 5.3 | Dropping speed loaded/without load |
m/s | 480/420 |
| 5.4 | Maximum traction,loaded |
N | 15000 |
| 5.5 | Max grade ability,loaded/without load |
% | 12/15 |
| Drive | |||
| 6.1 | Drive motor power | kw | 8 |
| 6.2 | Drive motor power | kw | 7.5 |
| 6.4 | Level voltage/Capacitance | V/Ah | 48/450 |
| Others | |||
| 7.1 | Drive System | DC/AC | |
| 7.2 | Electrical control system | Curtis from America | |
Q: Are you trading company or manufacturer ?
A: VMAX was founded in 2010, is a professional production and sales of forklift manufacturer.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-45 days if the goods are not in stock, it is according to quantity and model.
Q: Do you provide samples ?
A: Yes, VMAX accept the sample order.
Q: What is your terms of payment ?
A: T/T and L/C is accepted.
