1300-1800 Mpa Fine Screen Steel Wire Cloth 65mn High Tensile Rolls For Quarry Industry

 Mam Ba 65Mn Wire Cloths

Mam Ba Screen Mesh MFG Company’s strict quality control system starts at the very beginning: selecting the right material. There are more than 500 steel works in China. We only chose 2 of them as our material suppliers. Except their stable quality (and good qualification we need), they must be able to customize steel wire rods in accordance with correct composition ratios we provide. Most importantly, they must be able to provide the test report of SGS, the international third party test organization for every batch of steel wire rods they produced.

Then these steel wire rods, the most suitable material for wire cloth, will be sent to China Juli Group. As our long-term partner, Juli Group, the biggest Sling manufacturer in the world, owns the most advanced wire drawing and heat treatment technique. Here, wires are taking lead patenting process to change their basic micro structure and texture to gain more fine grained pear lite. It is a necessary step to make sure our woven wire cloth features high tensile strength and better ductility.

Now, the material stage is ready. The wires will face one more test after they enter our factory. Our Quality Supervision Department will check its tensile strength, diameter and wire surface to decide if it can meet out company own standard which is actually higher than our National Standards.

1.Carbon Steel Wire Parameter:

2.Stainless Steel Wire Paramter:

Opening size:

1 - 152.4 mm

Wire diameter:

0.5 - 19.05mm
Hole type: square, rectangular and long slot.

Supplied dimensions:

as required by customer.Rolls or Cut to Flat Plate

Aperture, Wire Diameter and Diagonal Error or Tolerance:

1. Aperture error: ≤3%,which is better than International Standards;

2. Wire diameter error: ±3%;

3. Diagonal error: ≤9mm every 2m;

It ensures every piece of wire cloth we made can be etching with remarkable sign of Mam Ba: square, flatness and right tightness.



The 65Mn Wire Cloths are manufactured with an industry-leading stringent wire opening of ±3% and extremely tight crimps and weave for a longer wear life and the elimination of premature failure.

Twin Wire Screen Mesh The Benefits Are Clear

1. Handles high-impact loads & wears better than heavier single-strand wire

2.Excels with large feed materials

3. Reduces screen cloth change-outs & production costs per ton

4. Improves material throughput by up to 50% with more open area than perforated punch plate

5. Increases the volume of material you can process

6. Reduces installation time because the two lighter-weight wires bend easier than one heavy wire


Edge Types:





 Weaving Type:






Screen Cloths Mesh 5 Main Applications:

1. Sand Aggregate (Quarries)

2. Mining Companies & Mining Machinery

3. Road Construction Companies & Road machinery

4. Hot Mix Asphalt (HMA) Plants

5. Construction materials recycle


Mam Ba 65Mn Wire Cloths be used Cases:
