F55 / S32760 Super Duplex Stainless Steel Plate Zeron 100 Material ASTM A240

F55 / S32760 Super Duplex Stainless Steel plate Zeron 100 Plate 25%Cr Duplex Pren ≥40.0
UNS S32760 25% chromium duplex stainless steel

Regular size(mm):

Cold rolled sheet
0.5 * 1219 * C

1.0 * 1219 * C

1.5 * 1219 * C
2.0 * 1219 * C

2.5 * 1219 * C

3.0 * 1219 * C

Hot rolled Plate
3.0 * 1500 * c

4.0 * 1500 * c

5.0 * 1500 * c
6.0 * 1500 * c

8.0 * 1500 * c

10 * 1500 * c
12 * 1500 * c

14 * 1500 * c

16 * 1500 * 6000

18 * 1500 * 6000

20 * 1500 * 6000
25 * 1500 * 6000

30 * 1500 * 6000

Special sizes can be customized according to customer requirements

General attributes:

UNS S32760 is a super duplex stainless steel. Contains 0.75% tungsten and copper, 25% chromium (austenite / ferrite) steel. The alloy's PREn (pitting equivalent) number is> 40.0, which ensures high pitting resistance. Zeron 100 has high mechanical strength, good ductility, and corrosion resistance to the marine environment at both atmospheric and sub-zero temperatures. Good resistance to abrasion, corrosion and cavitation and can also be used in the working environment of acid media.

Mainly used in oil and gas and offshore applications, typically in pressure vessels, choke valves, Christmas trees, flanges and piping systems.

Its chemical composition is shown below

National standards:

ASTM / ASME: A240-UNS S32760

DIN / EN 1.4501, ASME SA-240

Mechanical properties Tensile strength: σb≥750Mpa Elongation: δ≥25%
Material description: The main chemical components Cr, Ni, Mo, N, etc. have a certain degree of improvement over 2205, 2304, 2101. It has better performance in terms of oxidation resistance, acid corrosion resistance, seawater corrosion resistance, chloride ion corrosion, etc. It also has good strength.
Typical working conditions :30% dilute sulfuric acid, below 60 ℃, annual corrosion rate <0.1mm

Matching Welding Material:E2594
