Smart Commercial Electric Vehicle Charging Stations 7 Kw Type 2 AC Charger
New Electric Vehicle 7 KW Smart AC Charging Pile With Rfid Cards , Case B connectors,Type 2 AC Charger
Short Description:
7KW commercial charger is designed for public use with RFID authentication. Equipped with a type 2 charging socket, the charger is compatible with either type 1 or type 2 cable.
Compliant with the industrial standards, the charger use MID certified meter to ensure accuracy and built-in RCD to secure safety.
The charger can be connected to a charging network with the help of EN-GATE gateway. Multiple public chargers in one location can be integrated in the network with only one internet communication connection.
Key Features:
Output Current: 32A
One Type 2 charging socket
MID certified energy meter
RCD Type A+6MA DC detective
Compliant with OCPP 1.6 ( JSON)
RFID function
Protection Grade: IP54
Warranty: 2 years
Stable
Both control circuit and power circuit are completely isolated. Increased anti-jamming capacity to ensure stable working condition.
Secure
Offer creative protection from hit or knockdown, if the inclination angle is over 30°, unit will terminate power automatically, report failure to operating system, removing any danger.
Simple but robust
Tempered glass panel and all metal case. IP65 protection grade higher than industrial standard. Simple and elegant product, providing quality inside and out.
Reliable
Built for extreme environment such as -30°C ice and snow season or 55°C hot and direct sunshine. Core parts take industrial grade components and offer 15-year design life.
Intelligent
Real-time searching, reservation, fast charging via mobile application. Flexible payment options including RFID card, and mobile payment such as PayPal, AliPay, Apple Pay, etc.
Energy saving
Standby power consumption is less as 3~6W, energy efficiency increase twice than same-level product in the market, minimizing operation cost.
| Datasheet | Model | AC7000-BE-34 | ||
| Input | Power Supply | 1P+N+PE | ||
| Rated Voltage | 230V AC | |||
| Rated Current | 32A | |||
| Frequency | 50/60Hz | |||
| Output | Output Voltage | 230V AC | ||
| Maximum Current | 32A | |||
| Rated Power | 7KW | |||
| User Interface | Charge Connector | Type 2 socket | ||
| Enclosure | Plastic PC940 | |||
| Front Panel | Temper glass | |||
| LED Indicator | Green/Yellow/Red | |||
| LCD Display | 2.7'' black & white screen | |||
| RFID Reader | Mifare ISO/IEC 14443 A | |||
| Start Mode | Plug&Play/RFID card/App | |||
| Emergency Stop | No | |||
| Communication | WiFi | Yes | ||
| Ethernet | Optional | |||
| 3G/4G | Optional | |||
| OCPP | OCPP 1.6 JSON (OCPP 2.0 optional) | |||
| Sefety | Energy Meter | MID certified | ||
| RCD | 30mA Type A + 6mA DC | |||
| Ingress Protection | IP54 | |||
| Impact Protection | IK08 | |||
| Electrical Protection | Over current protection, Residual current protection, Short circuit protection, Ground protection, Surge protection, Over/Under voltage protection, Over/Under frequency protection, Over/Under temperature protection | |||
| Certification | CE | |||
| Certification Standard | EN/IEC 61851-1: 2017, EN/IEC 61851-21-2: 2018 | |||
| Warranty | 2 Years | |||
| Environment | Installation | Wall-mount/Pole-mount | ||
| Work Temperature | -30℃~+50℃ | |||
| Work Humidity | 5%~95% | |||
| Work Altitude | <2000M | |||
| Package | Product Dimension | 356*221*136MM (H*W*D) | ||
| Package Dimension | 490*330*210MM (L*W*H) | |||
| Net Weight | 3.4KG | |||
| Gross Weight | 4.2KG | |||
| External Package | Carton | |||
