Heat Treatment Gas Push Plate 24h Industrial Ceramic Furnace
Price:
Negotiable
MOQ:
1 Set
Delivery Time:
Negotiable
Brand:
Yan Yang Tian
Product Description
Electronic Ceramic Firing High - Temperature Gas Push Plate Furnace
1, Product Overview
2, Parameter attribute table
| The main technical parameters | |
| Chamber length |
9-15m |
| Common temperature |
1400-1600℃ |
| Temperature uniformity | ± 5 ℃ (constant temperature area) |
| Design maximum operating temperature |
1700℃ |
| Production into the furnace mode | Single push plate, double push plate |
| Supporting push plate conventional size | 250mm × 250mm; 320mm × 320mm, etc. |
| Heating temperature zone | Zone 5-8, 10-16 temperature control points, push the upper and lower temperature control |
| Control mode | SCR control, intelligent instrument PID continuous adjustment, PLC + touch screen automatic monitoring |
| Furnace structure | Modular assembly |
| Propulsion mode | Fully automatic hydraulic propulsion external circulation system |
| Electric heating element | Silicon molybdenum rod |
3, Product application
It is mainly used for high-temperature sintering of various structural ceramic products such as 95 porcelain pieces, 99 porcelain pieces, 5G porcelain pieces, zirconia products, corundum porcelain pieces, etc., which is suitable for continuous production.
Please contact us for specific details, we will tailor-made for you!
