Crystal Glass Mosaic Production 900℃ Electric Industrial Furnace
The Common Temperature For Producing Crystal Glass Mosaic In Glass Furnace Is 900 ℃
The company provides crystal glass mosaic production line
1. Control mode: PID intelligent control system, multipoint control
2. Furnace structure: modular; on-site assembly
3. Roller material: stainless steel rollers and high-temperature ceramic rollers are used in different parts of the Furnace as required
4. Heating mode:Electricity, natural gas, liquefied petroleum gas
| The main technical parameters | |
| Furnace length |
26-60m |
| Roller diameter |
Ø40-60mm |
| Chamber width |
800-2500mm |
| Temperature control precision |
±1℃ |
| Maximum use temperature |
1000℃ |
| Transfer method |
Helical gear transmission |
|
Common temperature |
≤900℃ |
| Daily output (24h) | 100-1500 square meters / day |
| Roller speed | Frequency control |
- Non-standard customized equipment, mainly used for the continuous production of crystal glass mosaics
- Production line equipment composition: glass cutting machine, printing and drying line, breaking and typesetting machine, edge melting furnace, back film drying line and other equipment.
Our company provides a full set of technology and equipment for crystal mosaic production, please contact us for details, we will tailor it for you!
1. Are you a trader or a manufacturer?
We are a company, we have our own factory
2. How long is your delivery time?
Negotiable
3. Can the product be customized?
Can be customized
4. What does the product packaging look like?
Export packaging or according to customer requirements
