Medicine Industry Two Way DN1000 SS304 Diverter Ball Valve
Good quantity two-way Diverter Valve from China
| Structure type | Ball Type | Plug Type | Rotating Plate Type | Swing Plate Type |
| Piping Include Angle | 45° | 30° | 22.3° | 45° |
| 60° | 45° | 30° | 60° | |
| 90° | 60° | 45° | 90° | |
| 120° | 90° | 60° | 120° | |
| Main Size | DN40-600 | DN50-800 | DN50-800 | DN100-1000 |
| Working Pressure | ATM/LP | MP | HP | |
| ATM/<0.1Mpa | 0.15~0.35Mpa | >0.35Mpa | ||
| Working Temperature | -20℃~200℃/≤450℃/≤720℃ | |||
| Main Materials | SS304, SS304L, SS316, SS316L, SS836L, WCB, QT500 and etc. | |||
| Flange Conn. Rating | ANSI B16.5 150LB, GB, HG, SH or designated by client | |||
| Applicable Medium | Solid material(Power, particles, powders/particles mixtures, flakes and etc) | |||
The related technical parameters of two way diverter valve:
Two way diverter valve feature:
1. Good sealing performance of ball type diverter valve
2. The client can select the suitable installation angle and direction freely, as per the need of conveying pipeline.
3. Under the pressure and seal conditions, special seal structure can be equipped to fully satisfy with the application requirement.
Application of ball type diverter valves feature:
This ball type diverter valve is mainly used in the conveying system. Its fully closed construction is suitable for outdoor environment.
Hanrui Puzer is professional as one of the leading two way diverter valve manufacturers and suppliers in China. Equipped with advanced equipment and experienced staff, we now have high quality products for sale. Should you have any interest in it, please feel free buy two way diverter valve at best price with us. We will offer you the greatest after-sales service and fast delivery.
