Anti Earthquake 8 Degree Light Steel Prefab House Thickness 1.0 For Stud Framing
Price:
USD180-USD250 per square meter
MOQ:
50 square meters
Delivery Time:
Negotiable
Brand:
Sussman
Product Description
Anti Earthquake 8 degree Light Steel Prefab House thickness 1.0 for the stud framing
Subject structure
The steel structure system adopts G550 steel, 1.0-1.8 mm thin-walled light steel keel system, and the structural connectors adopt 2.0 mm thick galvanized steel firmware.
Design parameters
Roof live load: 0.6kn/m2
Wind load: 30m-50m/s
Seismic Intensity: 9 Degrees
Service life: 50 years
| TECHNICAL PARAMATERS | |
| Steel Column | G550 AZ150 Galvanized Steel (Hot-formed Aluminum coating steel) |
| Roof Frame | G550 AZ150 Galvanized Light Steel keel |
| Structural slab | Oriented Stand Board(OSB board) |
| Insulation | Glass wool |
| Wall | Exterior wall cladding/Interior wall bamboo fiber board |
| Floor | Ceramic tile/wooden ground floor |
| Ceiling | 9mm Gypsum board/10mm Banboo fiber board |
| Electric | Ceiling lights, electric wire, socket |
| Window | Aluminum window/hollow glass window |
| Doors | Entrance door: steel security door, Inner door: wooden molded door |
| Toilet | Sprinkler, hand basin ,water closet |
| Drainage system | Provide plan, design and materials |
| Life span | 50 Years |
| Container loading | According to the order and custumer's requirements |
| Delivery time | 20-30 working days after recepting the deposit |
| Application | Hotel,House,Office,Shop,Villa |
Interior Decoration
