Sandwich Panel Light Steel Villa House / Contemporary Prefabricated Homes
Steel Sandwich Panel Prefab House Modern Prefabricated Homes Light Steel Housing/Modular Prefab House
The light steel prefabricated villa house is designed as per specific requirements of clients. It is designed by software with a very high preciseness for manufacturing. The frame is G550 and cold-formed AZ 150 galvanized and aluminum coated steel sheet.The steel frame thickness are 0.8mm,1.0mm and 1.2mm. The light steel villa house, because of its excellent physical performance and advanatges, is widely used as low-rise residential house,accommodation house,private villa,company office etc.It has won popularity in Europe,America,Australia,New Zealand,Japan,Middle East,Southeast Asia and Africa.
| Name | Description | Specifications |
| Steel frame | Color | As you required |
| Roof | Roof covering | 0.45mm thickness color steel sheet, white grey |
| Insulation | 100mm thickness glass wool, 12kg/m3, single faced aluminum foil | |
| Ceiling | YX12-110-880 flashing steel sheet, 0.35mm thickness, white grey | |
| Floor | Sub-floor | 0.3mm thickness color steel sheet |
| Insulation | 100mm thickness glass wool, 12kg/m3, single faced aluminum foil | |
| Floor | 18mm Glass Magnesium Board 1.6mm PVC floor (blue) | |
| Wall panels | Sandwich panel with EPS insulation | double faced 0.4mm color steel panel, 75mm insulation, 16kg/m3, |
| Window | Upvc window frame and sliding widow | White 1120*1100mm, hollow glass, with aluminum alloy rails |
| Door | Steel door | Right-hand inward-opening door, 845*2035mm |
| Electrics system | CEE industrial socket | 220V, 50Hz, three phase, 32A |
