Prefabricated Light Gauge Steel House / Luxury Modern Prefab Tiny Homes
Price:
USD180-USD250 per square meter
MOQ:
50 square meters
Delivery Time:
Negotiable
Brand:
Sussman
Product Description
Light Steel Frame Prefabricated House Prefabricated Modular Homes Prefab House Tiny House Low Price
General Benefits of Light Steel Frame.Most cost-effective mid-rise structural material.
Shorter and predictable construction schedule.Highest strength-to-weight ratio of any building material.100% recyclable.
68% industry recycling rate.Non-combustible - does not burn nor contribute fuel to the spread of a fire.
Inorganic - will not rot, warp, split, crack or creep.Dimensionally stable - does not expand or contract with moisture content.
- We have got the CE certificated for the light steel framing system. we can supply all the finishing materials that have the CE certificate.
- We have exported the products more than 50 country around the world. And have more than 10 years experience in this region.
- We supply the supervisor and labors if client need.
- We got the Australia standard window, sanitary, electrical, water pipe etc, and our framing system have already proved by the Australia Engineer.
- `We have more than 100000sqm factory area, and the manufacture capacity can be 30000sqm per month.
| Item | Details |
| Structure | Q550 Glavanized Steel |
| Steel Thickness | 0.8-1.5mm, Width 89mm |
| Galvanized Quantity | 275g/sqm |
| Wind Resistant | 12 Grade |
| Seismic Resistance | 9 Grade |
| Lifespan for structure | 90 Years at least |
| Floor load capacity | 250-500kgs/sqm |
| Sound Reaistant | 10-15dB Can reach 4 star hotel standard(40dB) |
| Genaral Lifetime | 70 Years |
| Connection Way | Bolted Connection |
| Plumbing and Electrilicy | Can be prefabricated, easily connect with local system |
| Installation | 100 sqm Double stories frame can be install in 10 days with 9 works |
