One Layer 2 Bedrooms 60m2 Prefab Modular Homes With Chimney
Price:
USD180-USD250 per square meter
MOQ:
50 square meters
Delivery Time:
Negotiable
Brand:
Sussman
Product Description
One Layer 60m2 2 Bedrooms With Kitchen Light Gauge Steel Prefab Modular Homes With Chimney
Prefab steel structure with panel is widely used as large factory, warehouse, workshops, storage, stadiums, offices, accommodation and other buildings. Steel structure building with ALC panel is a new type of building structure system, which is formed by the main steel framework linking up H-section, Z-section, and U-section steel components, roof and walls using a variety of panels and other components such as windows and doors.
| Building's Part | Description | Specification | ||
| Major Structure | Major Structure | Steel Frame | HANGANG Chinese Standard,G550-Z275 C-shaped Steel | According to design requirements |
| Consumables | Screw,bent parts,L parts,etc | According to design requirements | ||
| Roof | Deco Layer | Fiberglass reinforcement asphalt shingle | Standard 3mm thick | |
| Ceiling Insulation | Glass wool blanket | 100mm thick,18kg/m³ | ||
| Structural Layer | Oriented Strand Board | 1220*2440*12,waterproof type | ||
| Waterproof Layer | Waterproof roll | Two-sided Pressure Sensitive Adbesive SBS Sticky Roll | ||
| Cornice | Oriented Strand Board | 1220*2440*12,waterproof type | ||
| PVC cornice closure plate | white | |||
| Outer Wall | Outer Deco Layer | Vantilation Shutters | Vantilation | |
| Fiber-cement stack plate | 3600*210*8 | |||
| Filled Layer | Glass wool blanket | 100mm thick,18kg/m³ | ||
| Insulating Layer | XPS extruded polystyrene board | Grade B1,1200*600*50 | ||
| Rough Groud | Rough ground | antiseptic treatment,40*50 | ||
| moisture proffing course | Lamininating films | 0.35mm,unidirection | ||
| Structural Layer | Oriented Strand Board | 1220*2440*9, | ||
| Interior Wall | Dry Area | Paper double drywall | 1200*2400*9.5, | |
| Wet Area | Monolayer cement fiber board | 1200*2400*10 | ||
| Floor | Floor | Oriented Strand Board | 1220*2440*18, | |
| Door & Window | Entry Door | Steel Security Doors | 900*2100 | |
| Window | Aluminum Alloy Window | Double Glass Insulation Window | ||
