Compounding 0.426mm Steel Expandable Flat Pack Insulated Containers Home
Prefabricated 20ft 40ft Shipping Flat Pack Container Homes House For Camping
Sussman Flat Pack Container House Introduction:
This kind of container house is convenient in lifting, fixing and compounding. The construction of the house enables its compounding in longitudinal and transverse directions without limits, also enables compounding of containers into 2 floors (ground floor + first floor), or 3 floors. The frame of container house is light steel structure, including floor, roof and four corner pillars. The building materials and its specific physical properties offer a comfortable indoor condition and suit to various purposes. And all the materials that used are environmental friendly.
| Size | 20ft(6*2.5*2.7m) 40ft(6*5*2.7m) |
| 20ft (two options) | C100mm*100mm*2.5mm steel purlin |
| C160mm*160mm*3.0mm steel purlin | |
| 40ft (two options) | C100mm*100mm*3.0mm steel purlin |
| C160mm*160mm*3.5mm steel purlin | |
| Floor(Assembled) | 18mm MGO board/Cement fiber board+PVC floor(optional) |
| Wall Panel | 0.326/0.426mm thickness Color steel sheet +50/75/100 thickness EPS/glass wool/rock wool/PU insulation |
| Roof Panel (Assembled) | 0.4mm thickness Aluminized zinc color steel plate+50mm thickness Glass wool insulation+0.326/0.5mm thickness pressed color steel sheet ceiling |
| Window | PVC Sliding window with theft proof bar |
| Door | Steel door |
| Packing | 6 units container house can be fully fitted in a 40'HQ |
Effect Picture:
Sussman Flat Pack Container House Advantage:
1. Roof panel and bottom panel have been finished in factory ,easier to install.
2. Total-sealed-top and corner-draining system,ensures no water leaking on roof top, it will be 100% water-proof.
3. Fully galvanized for the steel structure. Fully Welded Top frame + truss and Bottom frame + supports ensure product strength!
4.The Columns are powder painted, not the normal paint spraying,it will be more smooth.
5. The position of door and window could be freely adjusted.
6. It is movable and portable, easy to move and transport.
7. Fire proof sandwich panel for roof and wall.
