Fever Detection AR Police Smart Temperature Measuring Helmet
Infrared Thermal Imaging AR Police Helmet
Wuxi Xinzheng Precision Machinery Manufacturing Co., Ltd. does its best to fight the epidemic with all people around the world, and develops products based on years of experience in precision instruments: Smart Body Temperature Measuring Instrument --Automatic Smart Interactive Helmet
Technique data sheet
|
Basic Info |
|
|
Power |
DC 5V/3A |
|
Processor |
Cortex A53*4, |
|
Memory |
LP DDR 4GB |
|
Storage |
eMMC 16GB; MicroSD Slot*1, |
|
Operation System |
Android 9.0 |
|
USIM |
for 4G LTE |
|
Connectivity |
WiFi: 802.11a/b/g/n/ac, Bluetooth 5.0 |
|
Weight |
1.00Kg |
|
AR Display |
|
|
Field of view |
40 degree |
|
Pupil distance |
18mm |
|
Resolution |
1920*1080 |
|
Brightness |
1-900 nits |
|
Virtual screen size |
Equivalent to 86 inch from 3m away |
|
Temperature test |
|
|
Resolution |
120*90@17μm WLP |
|
Focus |
2.3mm F1.1 |
|
Field of view |
50° |
|
Resolution of temperature |
≤±0.5 with 1.5m distance in 32℃-42℃ |
|
Number of monitoring targets |
5 |
This combination of optical waveguide display technology and digital twin technology is equipped with high-precision infrared thermometers, thin and light AR glasses, and the application of virtual-real fusion technology to realize real-time perception and decision-making of virtual and real environments. Provide new technical means such as production control operations. At the same time, it has the function of self-adaptive calibration of ambient temperature and humidity, which can realize the temperature measurement of non-contact people, and ensure that workers can carry out epidemic prevention inspection at a safe distance.
Automatic Smart Interactive Helmet can provide safe epidemic inspection solutions for public places such as highway junctions, stations, airports, schools, etc.
