3 In 1 Motorized Card Reader And Writer Supports RF/IC Card R/W And Magnetic Card
OVERVEIW
RCM-5510 series motorized card reader/writer supports RF/IC card R/W and magnetic card R, which is a product created from many years of technology and experience accumulation and the market demand.
RCM-5510 is designed based on the development concept that integrates multiple functions. Careful material selection, rational structure, and stable circuit design make it a highly reliable product. all these enable A6 to better meet the market requirements for motorized card reader/writer.
FEATURES
It Supports reading and writing three types of cards: magnetic card, ic card, and id card.
Its interface is RS232.
It is electric and has a plastic case. Its demensions is 145*84*47.4mm
It has a long service life, the magnetic head's lifespan is 800,000times,the IC card contactt point's lifespan is 500,000 times and the trans equipment's lifespan is 500,000 times.
Magnetic signal, Optoelectronic signal and rear card insert
SPECIFICATIONS
| Operation Power | DC 12 V ( MAX CURRENT 3A, Static current 100mA), Recommend :12V/3A |
| Operation Te-mp.&Humi. | 0 ℃ ～ 50 ℃ ,30～90% (Relative Humidity) |
| Interface | RS232 serial port , Support 2400～ 38400BPScommunication rate |
| Card size : | Card width:54±0.5mm Card length:85±0.5mm Card thickness:0.2-2.0mm |
| Magnetic card type | ISO7810 ,ISO7811 (1-6－) ,ISO7812 ,ISO7813 And ISO15457 |
| contact IC card type | ISO7816 normal storage card,logic encryption card, and smart card(CPU card), reading and writing support |
| contactless IC card type | ISO14443 TYPEA TYPEB 1,5693 contactless card reading and writing |
APPLICATIONS
ATMs
CDMs
Kiosk Terminals
Payment Systems
Vending Machines
Gaming Machines
Parking Systems
Fuel Dispensers
CNG Dispensers
Sales & Service
rCloud provide Communication Protocol, SDK for customers to develop.
rCloud provide technical support to customers when they met problems in develop processing.
rCloud provide high-quality products to customers.(Every products will pass three times strict tests before delivery).
rCloud provide OEM products to customers.
rCloud provide a high efficiency team and pleasure purchase process to customers.
