0.08mm Pvc Coated Overlay With Magnetic Stripe For Loyalty Cards
0.08mm Pvc Coated Overlay With Magnetic Stripe for loyalty cards
Production Specification
| 1.0.08mm Pvc Coated Overlay With Magnetic Stripe for loyalty cards- Introduction |
PVC coated overlay with magnetic stripes MCO-MS is applied with standard magnetic stripe. It applies the high-quality magnetic stripe made by LUCKY China. It can be directly laminated with the printing sheets in the card laminator before punched into standard magnetic card. It features high adhesion, no color change and deformation with long aging life after the process of lamination.
| 2. 0.08mm Pvc Coated Overlay With Magnetic Stripe for loyalty cards - Specification |
Specifications:
| Product name | A4 Size Black Magnetic Stripes Coated Overlay Sheet For Plastic Card Lamination |
| Common size | A4, 310x480mm (A3, customized ) |
| Thickness | 0.04mm -1.0 mm |
| Appearance | transparent |
| Coated | glue on back |
| Laminating temperature | 110-150℃ |
| Storage | -10~35℃, sealed, moisture-proof |
| Shelf life | 2 years |
| Packing method | 100pcs/bag, 4000pcs/carton |
| 3. 0.08mm Pvc Coated Overlay With Magnetic Stripe for loyalty cards - Product Parameter |
Thickness of overlay: 40-100 Micron
Size: Sheet size or Roll size
Classify: HI_CO 2750OE, LO_CO 360OE
Overlay Type: Coated Overlay, Uncoated Overlay
Magnetic stripe: Lucky or customized.
Technical note: In manufacturing process, it can be directly laminated with PVC printing sheet, simplify the fabrication process, save time, adhesive strength is high.
The technical Parameters:
| Model number | MCO-MS |
| Thickness | 0.04 mm,0.05mm,0.06mm ,0.08mm ,0.10mm |
| Common Size | Sheet size or Roll size, any size as your requirement |
| Color | Clear (Transparent) |
| Glue Coated | Yes |
| Application | Magnetic strip Card Making |
| Type | Heat press |
| Advantage | Waterproof, Moistureproof, Customized layout |
| Packaging method | By standard export carton and packed in strong plywood pallet with proper soft protection material inside, suitable for long distance for sea or air transport |
| 4.0.08mm Pvc Coated Overlay With Magnetic Stripe for loyalty cards- Application |
In manufacturing process, Magnetic Stripe PVC Film can be directly laminated with PVC printing sheet, simplify the fabrication process to save time.
Steps to make cards:
1).Put printing core and two overlays together, then put into the laminator.
(The laminating temperature and time is determined as per the instruction of the machine). Please be noticed that all glue sides of both PVC sheets and overlays are put inward.
2).Lamination lasts 10-15 minutes (6-8Mpa 125-140℃).
3).Cutting.
