0.04mm PVC Card A4 A3 Size Magnetic Stripe Coated Overlay Film

0.04mm PVC Card A4 A3 Size Magnetic Stripe Coated Overlay Film

Production Specification
1.0.04mm PVC Card A4 A3 Size Magnetic Stripe Coated Overlay Film Introduction

0.04mm PVC Card A4 A3 Size Magnetic Stripe Coated Overlay Film is applied with standard magnetic stripe. It applies the high-quality magnetic stripe made by LUCKY China . It can be directly laminated with the printing sheets in the card laminator before punched into standard magnetic card. It features high adhesion , no color change and deformation with long aging life after the process of lamination .
Procedure to produce cards:
1. Put PVC printing core and two overlays together , then put into the laminator . ( the laminating temperature and time is determined as per the instruction of the machine ) . Please be noticed that all glue sides of both PVC sheets and Overlays are put inward .
2. Tlamination lasts 10-15 minutes . The pressure is 6-8Mpa. The temperature is 120-140°C.
3. Cutting the card.



2.0.04mm PVC Card A4 A3 Size Magnetic Stripe Coated Overlay Film Specification
Product Parameter :

1.Size: in sheet, A4, A3 or as per customer requirements
2. Coated overlay thickness range in mm: 0.04,0.05,0.06,0.08,0.10
3. Magnetic stripe feature: HICO/LOCO, standard width 12.7mm, black color, Peelable transfer model, Brand: LUCKY
4. Size tolerance: +/-0.5 mm in length and width, +/-5% in thickness.
5. Color : transparent with one-side glue coating
6. Length and width: in sheet, 201*297 mm ( A4 ) , 310*480 mm ( A3 ) or custom-made size (size tolerance: ±1mm)

7. Package method: 100/200 sheets per bag or as per customer requirements.

8. Storage condition: Sealed, moisture-proof, room temperature under 40℃, Keep it horizontally, avoid heavy pressing and direct sunlight.

Specifications:

Lamination Temperature	120-140 ℃
Thickness of overlay	0.04~0.1mm
Size	Sheet size or Roll size, any size as your requirement
Classify	HICO 2750OE, LOCO 360OE
Color	Clear (Transparent)
Glue Coated	YES



Model number	MCO-MS
Normal Thickness in mm	0.04,0.05,0.06,0.08,0.10
Normal Size	Sheet size or Roll size, any size as your requirement
Color	Clear (Transparent)
Glue Coated	With coating on both sides
Material	PVC
Application	Magnetic Strips Card Making
Laminating Type	Hot pressing
Advae	Waterproof, Moistureproof, Customized layout
Packaging box	In standard export carton or strong plywood package with  proper soft   protection material inside, suitable for long distance for sea or air transport

3.Application of 0.04mm PVC Card A4 A3 Size Magnetic Stripe Coated Overlay Film
 0.04mm PVC Card A4 A3 Size Magnetic Stripe Coated Overlay Film can be directly laminated with PVC printing sheet, which will simplify the fabrication process, save time.

4.Packing of Magnetic Stripes Coated Overlay Films
In standard export carton and are packed plywood pallet
