Metallurgy Carbon Steel Single Inlet Centrifugal Fan High Temperature
Carbon Steel Single Inlet Metallurgy High Temperature Centrifugal Fan
Introduction
9-03 series fan-type iron furnace special high-pressure centrifugal fan, is suitable for IL/h, 2L/h, 3L/h, 3L/h, 7L/h melting rate of iron furnace blast performance requirements.
The parts are closely matched and have good sealing performance to ensure the output pressure will not be reduced.
Technical data
| series | model | Rotation Speed (r/min) |
Total Pressure (Pa) |
Air Capacity (m³/h) |
Power (kW) |
|---|---|---|---|---|---|
| 9-03 | 4D | 2900 | 2285～2452 | 3297～6594 | 5.5～7.5 |
| 4.5D | 2900 | 2893～3060 | 4695～9389 | 11～15 | |
| 5D | 2900 | 3570～3854 | 6440～12880 | 15～22 | |
| 5.6D | 2900 | 4482～4805 | 9048～18095 | 30～45 | |
| 6.3D | 1450 | 1422～1500 | 6441～12882 | 7.5～11 | |
| 7.1D | 1450 | 1804～1942 | 9220～18439 | 11～18.5 | |
| 8D | 1450 | 2285～2462 | 13189～26378 | 18.5～30 | |
| 9D | 1450 | 2893～3099 | 18779～37558 | 37～55 | |
| 10D | 1450 | 3570～3854 | 25760～42933 | 55～90 | |
| 11.2D | 960～1450 | 1961～4835 | 23961～72381 | 30～160 | |
| 12.5D | 730～960 | 1412～2638 | 25329～66620 | 22～90 | |
| 14D | 730～960 | 1775～3305 | 35586～93596 | 45～160 | |
| 16D | 730～960 | 2314～4295 | 53120～139712 | 75～280 |
FAQ
1,Q: What’s the MOQ of your company?
A: The MOQ is 1set.
2,Q: How long is the delivery time?
A : A:5-35 days.
3,Q : What’s your payment terms?
A : T/T, L/C, or Negotiable.
4,Q: What’s your warranty?
A: 1 year.
5,Q: Is your company factory or trade company?
A: We have our own factory, our type is factory +trade.
Application
Centrifugal fan is applied in industrial boiler, (centrifugal fan can be applied in industrial boiler,) it also can be applied in industrial kilns, blast furnace, Industrial waste heat recovery device, Electrolytic aluminium production line air purification system and other industrial work environment.
