Customized Petrochemical Coking Unit Storage Tank Odor Treatment Supporting Zero Leakage Sealed Fan Blower
Price:
$500-1,0000.00/set
MOQ:
≥1 set
Delivery Time:
35days (To be negotiated)
Brand:
SIMO BLOWER
Product Description
Customized petrochemical coking unit storage tank odor treatment supporting zero leakage sealed fan blower
We offer customized sealed fans for odor treatment in petrochemical coking unit storage tanks, featuring a zero-leakage design to ensure efficient odor management. These fans are specifically engineered for harsh environments, providing excellent corrosion resistance and reliability, suitable for various applications in the petrochemical industry, ensuring safety and environmental protection.
Product features
1. It can output high pressure and is suitable for any industrial occasion where high pressure & normal temperature gas is required.
2. The energy transfer efficiency is high, the energy of the motor is directly applied to the impeller, and there is no energy consumption during the transfer.
3. The motor uses high-efficiency and energy-saving motors from China's leading motor manufacturers (and can also install branded motors required by users), with reliable quality and lower energy consumption.
4. It is made of high quality carbon steel, stainless steel or other metal materials are available upon request.
5. The impeller is subjected to a high standard of dynamic balance correction to ensure stable operation of the fan.
6.After the completion of production, after running test and vibration value detection, the operation is reliable.
2. The energy transfer efficiency is high, the energy of the motor is directly applied to the impeller, and there is no energy consumption during the transfer.
3. The motor uses high-efficiency and energy-saving motors from China's leading motor manufacturers (and can also install branded motors required by users), with reliable quality and lower energy consumption.
4. It is made of high quality carbon steel, stainless steel or other metal materials are available upon request.
5. The impeller is subjected to a high standard of dynamic balance correction to ensure stable operation of the fan.
6.After the completion of production, after running test and vibration value detection, the operation is reliable.
The following datas are only part of performance of our product.
If you can't find the datas you need, pls send us your performance requirements
we will provide you customized design service.
![Customized Petrochemical Coking Unit Storage Tank Odor Treatment Supporting Zero Leakage Sealed Fan Blower]()
If you can't find the datas you need, pls send us your performance requirements
we will provide you customized design service.
| series | model | Rotation Speed (r/min) |
Total Pressure (Pa) |
Air Capacity (m³/h) |
Power (kW) |
| 9-12 | 4D | 2900 | 2285~2452 | 3297~6594 | 5.5~7.5 |
| 4.5D | 2900 | 2893~3060 | 4695~9389 | 11~15 | |
| 5D | 2900 | 3570~3854 | 6440~12880 | 15~22 | |
| 5.6D | 2900 | 4482~4805 | 9048~18095 | 30~45 | |
| 6.3D | 1450 | 1422~1500 | 6441~12882 | 7.5~11 | |
| 7.1D | 1450 | 1804~1942 | 9220~18439 | 11~18.5 | |
| 8D | 1450 | 2285~2462 | 13189~26378 | 18.5~30 | |
| 9D | 1450 | 2893~3099 | 18779~37558 | 37~55 | |
| 10D | 1450 | 3570~3854 | 25760~42933 | 55~90 | |
| 11.2D | 960~1450 | 1961~4835 | 23961~72381 | 30~160 | |
| 12.5D | 730~960 | 1412~2638 | 25329~66620 | 22~90 | |
| 14D | 730~960 | 1775~3305 | 35586~93596 | 45~160 | |
| 16D | 730~960 | 2314~4295 | 53120~139712 | 75~280 |
Pursue excellent quality, make perfect product!
