132kW High-Flow-Rate High-Efficiency Boiler Fan
Our 132kW high-flow-rate boiler fan delivers exceptional performance for industrial and utility boiler systems, combining powerful air movement with leading energy efficiency. Engineered with a dynamically balanced impeller and advanced aerodynamic profile, it ensures stable, high-volume airflow for combustion optimization, flue gas recirculation, and ventilation applications.
| series | model | Rotation Speed (r/min) | Total Pressure (Pa) | Air Capacity (m³/h) | Power (kW) |
|---|---|---|---|---|---|
| 4-10 | 8D | 1450 | 2104～1400 | 16156～30993 | 18.55 |
| 9D | 960 ~ 1450 | 775 ~ 2668 | 15229 ~ 44128 | 11 ~ 37 | |
| 10D | 730 ~ 1450 | 553 ~ 3301 | 15886 ~ 60533 | 7.5 ~ 55 | |
| 11D | 730 ~ 1450 | 669 ~ 4003 | 21144～80570 | 11 ~ 90 | |
| 12D | 730 ~ 1450 | 797 ~ 4777 | 25661 ~ 104600 | 15 ~ 132 | |
| 14D | 730 ~ 1450 | 1086 ~ 6541 | 43591～166100 | 37 ~ 315 | |
| 16D | 580 ~ 960 | 895 ~ 3709 | 51699 ~ 164150 | 45 ~ 185 | |
| 18D | 580 ~ 960 | 1133 ~ 4710 | 73610 ~ 233730 | 75 ~ 280 | |
| 20D | 580 ~ 960 | 1400 ~ 5837 | 100970～320610 | 110 ~ 520 | |
| 22D | 480 ~ 960 | 1216 ~ 6865 | 116000～434000 | 140 ~ 850 | |
| 25D | 480 ~ 730 | 1579 ~ 5138 | 171000～484000 | 165 ~ 700 | |
| 28D | 375 ~ 730 | 1205 ~ 6400 | 187000 ~ 680000 | 320 ~ 1250 | |
| 29.5D | 596 ~ 745 | 3236 ~ 7218 | 348000 ~ 810000 | 800 ~ 1600 |
- It can work stably at a high medium temperature, and can output a large gas flow with low noise when the pressure requirement is met.
- The fan blade placement angle is optimized, more wear-resistant and longer service life.
- The air damper can be used to flexibly adjust the pressure and flow of the fan during operation. It is also possible to select a variable frequency motor, with adjust the pressure and flow of the fan by changing the speed.
- For the material of impeller and main shaft, we will choose high-strength carbon steel, low-alloy steel, high-temperature alloy steel, high temperature resistant high-strength alloy steel under different working conditions temperature and working speed, so that the impeller and main shaft still maintains a reliable strength at high temperature.
- Fan systems with impeller diameters less than 1400 mm at normal temperature do not require additional bearing cooling devices, reducing users’ investment and maintenance.
- The impeller is annealed to eliminate the internal stress generated during welding, ensuring that the impeller does not undergo creep and cracks.
- The weld of the impeller and the main shaft are ultrasonic flaw detection to ensure that there are no welding defects and material defects to ensure strength.
- The impeller is subjected to a high standard of dynamic balance correction to ensure stable operation of the fan.
- There are a variety of accessories to choose from.
Pursue excellent quality, make perfect product!
We are a professional centrifugal fan manufacturer integrating R&D, manufacturing, production, sales and after-sales service. We have 70 years of fan manufacturing and project experience. If you have fan needs, you can leave your fan requirements and parameter information, and our technical engineers will provide you with professional fan solutions.
