16Mn Coal Injection FAG Bearing Industrial Centrifugal Fans
16Mn Large Capacity Coal Injection Industrial Centrifugal Fans
Introduction
The 6-05 medium-pressure series fan can meet the performance requirements of large flow and high pressure at the same time, and has the characteristics of high efficiency and low noise. It is a series centrifugal fan products with a wide range of performance.
The designed max full pressure efficiency is higher than 80% new series boiler ventilation fans and induced draft fans with the low noise.
It can be selected if the intake conditions are equivalent and the performance is suitable.
It can be used to transport normal temperature or high temperature clean gas, dusty gas, flammable gas, corrosive gas, powder or granular materials, fiber materials, etc.
Technical data
| series | model | Rotation Speed (r/min) |
Total Pressure (Pa) |
Air Capacity (m³/h) |
Power (kW) |
|---|---|---|---|---|---|
| 6-05 | 3.55D | 2950～3150 | 588～1651 | 841～3162 | 1.5～2.2 |
| 4D | 3450 | 1676～1893 | 1355～3996 | 3 | |
| 4.5D | 2925～3250 | 1667～2873 | 2317～5522 | 4～5.5 | |
| 5.4D | 2600～2900 | 2064～3240 | 3900～8901 | 7.5～11 | |
| 7.1D | 1915～2100 | 1859～3283 | 7113～15919 | 11～18.5 | |
| 9D | 1640～1750 | 2191～3338 | 12407～25630 | 22～30 | |
| 10D | 1600 | 3444～2575 | 16604～32144 | 37 | |
| 11.2D | 1480 | 3697～2764 | 21578～41773 | 45 | |
| 4086～3055 | 21578～41773 | 55 |
FAQ
1,Q: What’s the MOQ of your company?
A: The MOQ is 1set.
2,Q: How long is the delivery time?
A : A:5-35 days.
3,Q : What’s your payment terms?
A : T/T, L/C, or Negotiable.
4,Q: What’s your warranty?
A: 1 year.
5,Q: Is your company factory or trade company?
A: We have our own factory, our type is factory +trade.
Application
Centrifugal fan is applied in industrial boiler, (centrifugal fan can be applied in industrial boiler,) it also can be applied in industrial kilns, blast furnace, Industrial waste heat recovery device, Electrolytic aluminium production line air purification system and other industrial work environment.
