Q235 Single Suction Long Life Industrial Dust Collector Centrifugal Flow Fan
Q235 Single Suction Long Life Industrial Dust Collector Centrifugal Flow Fan
Introduction
The fan can also be used in cement kiln decomposition process, steel smelting and other special occasions use of high temperature fan (use heat resistant & high strength material).
The 9-10.28 series high-pressure centrifugal fan is the latest developed high-efficiency and energy-saving product, whose performance fully meets the aerodynamic performance of general fan 9-08 series, and has the characteristics of high efficiency, low noise, flat performance curve, large flow regulation range and wide efficient area.
Technical data
| series | model | Rotation Speed (r/min) |
Total Pressure (Pa) |
Air Capacity (m³/h) |
Power (kW) |
|---|---|---|---|---|---|
| 9-13 | 4D | 2900 | 2285～2452 | 3297～6594 | 5.5～7.5 |
| 4.5D | 2900 | 2893～3060 | 4695～9389 | 11～15 | |
| 5D | 2900 | 3570～3854 | 6440～12880 | 15～22 | |
| 5.6D | 2900 | 4482～4805 | 9048～18095 | 30～45 | |
| 6.3D | 1450 | 1422～1500 | 6441～12882 | 7.5～11 | |
| 7.1D | 1450 | 1804～1942 | 9220～18439 | 11～18.5 | |
| 8D | 1450 | 2285～2462 | 13189～26378 | 18.5～30 | |
| 9D | 1450 | 2893～3099 | 18779～37558 | 37～55 | |
| 10D | 1450 | 3570～3854 | 25760～42933 | 55～90 | |
| 11.2D | 960～1450 | 1961～4835 | 23961～72381 | 30～160 | |
| 12.5D | 730～960 | 1412～2638 | 25329～66620 | 22～90 | |
| 14D | 730～960 | 1775～3305 | 35586～93596 | 45～160 | |
| 16D | 730～960 | 2314～4295 | 53120～139712 | 75～280 |
FAQ
1.Q: What parameters need to be provided when you design the industrial centrifugal fans?
A: Air flow rate(m3/h), Total pressure(Pa) or Static pressure(Pa), Inlet temperature(°C), Voltage and frequency on the working site.
2. Q:What is your delivery time?
A:15-35workdays, depending on the model of the fan.
3.Q:Are you manufacturer or trading company?
A:We are the professional manufacturer of centrifugal fans , over 65 years production experience and sales experience.
4.Q:What's your MOQ?
A:The MOQ is 1set,but larger quantity, lower price.
5.Q: What’s your warranty?
A: 12 months after arrival of the goods on site.
6.Q:How do you control the product's quality?
A:All the products have quality testing and dynamic balance before delivery.
Application
Centrifugal fan is applied in industrial boiler, (centrifugal fan can be applied in industrial boiler,) it also can be applied in industrial kilns, blast furnace, Industrial waste heat recovery device, Electrolytic aluminium production line air purification system and other industrial work environment.
