4 Inch Swivel Top Plate PU Castors

4 inch swivel top plate PU castor wheel

Description:

Widely used for carts, trolley,stereo equipment,exhibition equipment, tool boxes, equipment stands, mobile workstations, cabinets, dollies, mobile workstations ,etc

Finishes are available in either zinc plating, which provides durability under any condition, or stainless steel, which resists rust and corrosion in indoor or outdoor applications where moisture is a factor. Mounting options include standard swivel top plate, bolt hole and  threaded stem sizes.

Precision single ball bearing design that keeps you moving forward.

Technical parameters

swivel top plate -black PU caster wheel
Model	OY2-PU63-SBZ	OY2-PU75-SBZ	OY2-PU100-SBZ	OY2-PU125-SBZ
Caster diameter	63mm	75mm	100mm	125mm
Tread width	32mm	32mm	32mm	32mm
Load capacity	80kg	110kg	140kg	150kg
Total height	95mm	108mm	132mm	158mm
Hole spacing	75*45mm
Top plate size	95*65mm
Bearing	precision single ball bearing
Finish	zinc plating

swivel top plate with brake -black PU castors
Model	OY2-PU63-BBZ	OY2-PU75-BBZ	OY2-PU100-BBZ	OY2-PU125-BBZ
Caster diameter	63mm	75mm	100mm	125mm
Tread width	32mm	32mm	32mm	32mm
Load capacity	80kg	110kg	140kg	150kg
Total height	95mm	108mm	132mm	158mm
Hole spacing	75*45mm
Top plate size	95*65mm
Bearing	precision single ball bearing
Finish	zinc plating

fixed caster -black polyurethane wheel
Model	OY2-PU63-FBZ	OY2-PU75-FBZ	OY2-PU100-FBZ	OY2-PU125-FBZ
Caster diameter	63mm	75mm	100mm	125mm
Tread width	32mm	32mm	32mm	32mm
Load capacity	80kg	110kg	140kg	150kg
Total height	95mm	108mm	132mm	158mm
Hole spacing	75*45mm
Top plate size	95*65mm
Bearing	precision single ball bearing
Finish	zinc plating
