stainless steel 3 gallon water filling plant/device/unit single line for mineral water

This 3 gallon water filling plant is integrated with jar washing-filling-capping functions together;
Worker loads empty jar on jar holder manually, the jar holder with jar will be transferred in advance for jar washing, the transmission force is by gear cylinder;
Washing will be devided into 2 parts, 1st process is by disinfectant fluid, 2nd process is by pure water;After washing, the jars will be falling down on angle plate from jar holder by transmission chain with gravity force; Then the jars will be pushed by pushing cylinder to under filling head, then filling start; Filling volume can be controlled by filling time set up. The filled jars will be pushed to under capping head by empty jars afterwards. Worker put lot of disordered caps into cap loader, cap loader will sort cap automatically to load down into cap rail. When filled bottles passing under capping head, cap will fall down onto jar neck, then capping cylinder will do the capping automatically by cap pressing cylinder.

1. All PID control, full-automatic working, touch-screen control panel, easy to operate
2. Rotary filling style, fast, smoothly & steadily, ensure the high output capacity
3. No bottle no filling, no bottle no capping & high filling precision,
4. High precision filling nozzle, ensure no water drip during filling & same water level in the bottles
5. All 304 or 316L stainless steel contact parts, fine polish, ensure meet the Food Grade standards
6. Available Capacity of these series 5 gallon filling machinery: ( based on 5 gallon bottle)from 100BPh to 1200BPH
