Longitudinal Welding Astm A335 Carbon Steel Tube
Large Small Or Diameter Cs Carbon Steel Welded Tube Longitudinal Welding
Detailed Product Description
| Type | welded |
| Application | Food grade fluid pipe |
| Welding Line Type | Seamless and welded |
| Processing Service | Bending, WELDING, Decoiling, PUNCHING, Cutting, moulding |
| Surface | Mirror polish,matte finish,hair finish |
| Usage | Dairy,beverage,beer,pharmaceutical,etc. |
| Shape | Round Section |
ERW Line Pipe
Standard: API 5L
Steel Grade: GR.A, Gr. B, X42, X46, X52,X56,X56,X60,X70,X75,X80
ERW Galvanized Steel pipe
Standard: ASTM A53, BS1387 DIN 2440
ERW ASTM A178 Fire pipe
Standard: ASTM A53, ASTM A178
ERW Grooved Pipe
Standard: ASTM A53. ASTM A795
SSAW
Standard: ASTM, API, BS, JIS, GB, DIN
Steel Grade: Gr. A/B/C, X42-X80,
LSAW. UOE/JCOE
Standard: ASTM, API, BS, JIS, GB, DIN
Steel Grade: Gr. A/B/C, X42-X80
ERW Square/Rectangular tube:
ASTM A500, API, BS, JIS, GB, DIN16219/10210. Gr. A, Gr. B, Gr. C
BS1387-85 BLACK CARBON STEEL PIPE /ERW STEEL PIPE,light serie
Casing Pipe Standards: APL 5CT oil pipe
Casing Pipe Outside diameter: 73mm to 339.7mm (2-7/8" -13-3/8 ")
length : R1,R2,R3
Type of end finish in Casing Pipe: LTC, STC, BTC, plain end
Casing Pipe Packing: bundled with steel strip
Casing Pipe Application: Casing Steel pipe serves as wall of tubing in oil drilling field.
Casing Pipe Thickness: 5.51mm to 13.84mm (0.217" -1 ")
Casing Pipe Grade: K55 J55 N80
Casing Pipe Standards: APL 5CT oil pipe
Casing Pipe Outside diameter: 73mm to 339.7mm (2-7/8" -13-3/8 ")
Casing Pipe Thickness: 5.51mm to 13.84mm (0.217" -1 ")
Casing Pipe Grade: K55 J55 N80
length : R1,R2,R3
Type of end finish in Casing Pipe: LTC, STC, BTC, plain end
Casing Pipe Packing: bundled with steel strip
Casing Pipe Application: Casing Steel pipe serves as wall of tubing in oil drilling field.
| ERW STEEL PIPE | |||||
| O.D | O.D tolerance | W.T | Thickness Tolerance | ||
| 21.34—406.4mm | ±0.03 | 0.6—30mm | ±0.02 | ||
| Length | 2—16m, according to the customers’ requirements | ||||
| International Standard | ISO9001-2000 | ||||
| Standard | ASTM A53 / BS 1387-1985 | ||||
| Material | Q195/Q215/Q235/Q345/GR.B, GR.C | ||||
| Product Category | Matallurgy, Mineral & Energy | ||||
| Technique | Welded | ||||
| Packing | In bundles or according to customers’ request | ||||
| Usage |
1 For low pressure liquid delivery such as water, gas and oil 2 For construction, e.g building greenhouse |
||||
| Main market |
Middle east, Africa, North and South America, East and West Europe, South and |
||||
| HS code | 73063090 | ||||
| Productivity | 12000ton/month | ||||
| Processing technology available | Threading, coupling and with plastic caps protected | ||||
| Remarks | 1) Payment term: T/T 2) Trade Term: FOB/CFR/CIF 3) Minimum quantity of order: 10 MT 4) Delivery period: 10 to 30 Days |
||||
Mechanical Properties (MPa) (PSL1):
Standard |
Grade | (MPa) | (MPa) | A% | ||
| API SPEC 5L |
PSL1 | |||||
| ≥ | ||||||
| psi | MPa | psi | MPa | MIN(%) | ||
| B | 35,000 | 241 | 60,000 | 414 | 21~27 | |
| X42 | 42,000 | 290 | 60,000 | 414 | 21~27 | |
| X46 | 46,000 | 317 | 63,000 | 434 | 20~26 | |
| X52 | 52,000 | 359 | 66,000 | 455 | 20~24 | |
Grade and Chemical Composition (%)
Standard |
Grade | (MPa) | (MPa) | A% | (J) | ||
| API SPEC 5L |
PSL2 | ||||||
| Min | Max | Min | Max | Min | |||
| B | 241 | 448 | 414 | 758 | 21~27 | 41(27) | |
| X42 | 290 | 496 | 414 | 758 | 21~27 | 41(27) | |
| X46 | 317 | 524 | 434 | 758 | 20~26 | 41(27) | |
| X52 | 359 | 531 | 455 | 758 | 20~24 | 41(27) | |
Mechanical Properties (MPa) (PSL2):
Standard |
Grade | Chemical Composition(%) | ||||
| C | Mn | TI | P | S | ||
| B | ≤0.24 | ≤1.20 | ≤0.04 | ≤0.025 | ≤0.015 | |
| X42 | ≤0.24 | ≤1.30 | ≤0.04 | ≤0.025 | ≤0.015 | |
| X46,X52 | ≤0.24 | ≤1.40 | ≤0.04 | ≤0.025 | ≤0.015 | |
